git config --global credential.helper store
git clone https://sdk.aw-ol.com/git_repo/V853Tina_Open/manifest.git
repo init -u https://sdk.aw-ol.com/git_repo/V853Tina_Open/manifest.git -b master -m tina-v853-open.xml
由于repo更新，目前不支持通过repo输入密码，请先使用git命令输入保存密码
uboot和dtsi里面添加dual link IO的配置
demo:
lvds2link_pins_a: lvds2link@0 {
allwinner,pins = "PD0", "PD1", "PD2", "PD3", "PD4", "PD5", "PD8", "PD9", "PD6", "PD7", \
"PD10", "PD11", "PD12", "PD13", "PD14", "PD15", "PD18", "PD19", "PD16", "PD17";
allwinner,pname = "PD0", "PD1", "PD2", "PD3", "PD4", "PD5", "PD8", "PD9", "PD6", "PD7", \
"PD10", "PD11", "PD12", "PD13", "PD14", "PD15", "PD18", "PD19", "PD16", "PD17";
allwinner,function = "lvds1";
allwinner,muxsel = <3>;
allwinner,drive = <3>;
allwinner,pull = <0>;
};
lvds2link_pins_b: lvds2link@1 {
allwinner,pins = "PD0", "PD1", "PD2", "PD3", "PD4", "PD5", "PD8", "PD9", "PD6", "PD7", \
"PD10", "PD11", "PD12", "PD13", "PD14", "PD15", "PD18", "PD19", "PD16", "PD17";
allwinner,pname = "PD0", "PD1", "PD2", "PD3", "PD4", "PD5", "PD8", "PD9", "PD6", "PD7", \
"PD10", "PD11", "PD12", "PD13", "PD14", "PD15", "PD18", "PD19", "PD16", "PD17";
allwinner,function = "lvds1_suspend";
allwinner,muxsel = <7>;
allwinner,drive = <3>;
allwinner,pull = <0>;
};
dts中 修改为lvds dual link模式，并引用dtsi里配好的dual link IO
&lcd0{
...
lcd_lvds_if = <1>;
...
...
pinctrl-0 = <&lvds2link_pins_a>;
pinctrl-1 = <&lvds2link_pins_b>;
...
}
其他和single link的配置方法无异，如果点不亮请检查时序
这里看到dclk配置是80
但是手册需求的是54
这里提供一套1920x720的时序作为参考
&lcd0 {
lcd_used = <1>;
lcd_driver_name = "default_lcd";
lcd_backlight = <50>;
lcd_if = <3>;
lcd_x = <1920>;
lcd_y = <720>;
lcd_width = <150>;
lcd_height = <94>;
lcd_dclk_freq = <94>;
lcd_pwm_used = <1>;
lcd_pwm_ch = <3>;
lcd_pwm_freq = <50000>;
lcd_pwm_pol = <1>;
lcd_pwm_max_limit = <255>;
lcd_hbp = <64>;
lcd_ht = <2064>;
lcd_hspw = <20>;
lcd_vbp = <30>;
lcd_vt = <760>;
lcd_vspw = <10>;
lcd_lvds_if = <1>;
lcd_lvds_colordepth = <0>;
lcd_lvds_mode = <0>;
lcd_frm = <1>;
lcd_hv_clk_phase = <0>;
lcd_hv_sync_polarity= <0>;
lcd_gamma_en = <0>;
lcd_bright_curve_en = <0>;
lcd_cmap_en = <0>;
deu_mode = <0>;
lcdgamma4iep = <22>;
smart_color = <90>;
pinctrl-0 = <&lvds2link_pins_a>;
pinctrl-1 = <&lvds2link_pins_b>;
};
根据具体的模型和需求的规格来看，实际感觉差不多
重点：rootfstype=squashfs
v851s/configs/xxx/env.cfg
#kernel command arguments
earlyprintk=sunxi-uart,0x02500000
initcall_debug=0
console=ttyS0,115200
nand_root=/dev/ubiblock0_4
mmc_root=/dev/mmcblk0p4
nor_root=/dev/mtdblock3
init=/init
rdinit=/rdinit
loglevel=8
coherent_pool=32K
#reserve_list=30M@64M,78M@128M,200M@512M
mac=
wifi_mac=
bt_mac=
specialstr=
root_partition=rootfs
mtd_name=sys
rootfstype=squashfs
#set kernel cmdline if boot.img or recovery.img has no cmdline we will use this
setargs_nor=setenv bootargs earlyprintk=${earlyprintk} clk_ignore_unused initcall_debug=${initcall_debug} console=${console} loglevel=${loglevel} root=${nor_root} rootwait init=${init} rdinit=${rdinit} partitions=${partitions} cma=${cma} coherent_pool=${coherent_pool} ion_carveout_list=${reserve_list}
setargs_nand=setenv bootargs earlyprintk=${earlyprintk} clk_ignore_unused initcall_debug=${initcall_debug} console=${console} loglevel=${loglevel} ubi.mtd=${mtd_name} root=${nand_root} rootfstype=${rootfstype} rootwait init=${init} rdinit=${rdinit} partitions=${partitions} cma=${cma} mac_addr=${mac} wifi_mac=${wifi_mac} bt_mac=${bt_mac} selinux=${selinux} specialstr=${specialstr} coherent_pool=${coherent_pool} ion_carveout_list=${reserve_list}
setargs_nand_ubi=setenv bootargs ubi.mtd=${mtd_name} ubi.block=0,${root_partition} earlyprintk=${earlyprintk} clk_ignore_unused initcall_debug=${initcall_debug} console=${console} loglevel=${loglevel} root=${nand_root} rootfstype=${rootfstype} init=${init} partitions=${partitions} cma=${cma} snum=${snum} mac_addr=${mac} wifi_mac=${wifi_mac} bt_mac=${bt_mac} specialstr=${specialstr} gpt=1
setargs_mmc=setenv bootargs earlyprintk=${earlyprintk} clk_ignore_unused initcall_debug=${initcall_debug} console=${console} loglevel=${loglevel} root=${mmc_root} rootwait init=${init} partitions=${partitions} cma=${cma} mac_addr=${mac} wifi_mac=${wifi_mac} bt_mac=${bt_mac} selinux=${selinux} specialstr=${specialstr} coherent_pool=${coherent_pool} ion_carveout_list=${reserve_list}
#nand command syntax: sunxi_flash read address partition_name read_bytes
#0x4007f800 = 0x40080000(kernel entry) - 0x800(boot.img header 2k)
boot_partition=boot
boot_normal=sunxi_flash read 44800000 ${boot_partition};bootm 44800000
boot_recovery=sunxi_flash read 44800000 extend;bootm 44800000
boot_fastboot=fastboot
#recovery key
recovery_key_value_max=0x13
recovery_key_value_min=0x10
#fastboot key
fastboot_key_value_max=0x8
fastboot_key_value_min=0x2
#uboot system env config
bootdelay=1
#default bootcmd, will change at runtime according to key press
#default nand boot
bootcmd=run setargs_nand boot_normal
#verify the kernel
verify=N
会，启动介质优先级描述了每个介质被选择为启动介质的可能性。BROM 首先读取具有最高优先级的介质的 boot0。如果该介质不存在或存在任何问题，BROM 将尝试下一个介质。否则，该介质将被选择为启动介质。
具体可以查看手册GPIO Boot Select表格
@layzerlee 需要修改编译参数加上v扩展支持
CONFIG_TOOLCHAIN_MACH_FLAGS="-mcmodel=medany -mabi=lp64dv -march=rv64gcxvthead"
CONFIG_TOOLCHAIN_FPU_ABI="-march=rv64gcxvthead"
dclk过高，屏幕分屏了？
这里提供一个py脚本计算分频系数，这里对应的是HV屏，DSI也可以参考
def find_closest_clock(target_clock, clock_list):
clock_list = sorted(clock_list)
low, high = 0, len(clock_list) - 1
closest = clock_list[low]
while low <= high:
mid = (low + high) // 2
if clock_list[mid] < target_clock:
low = mid + 1
elif clock_list[mid] > target_clock:
high = mid - 1
else:
return clock_list[mid]
if abs(clock_list[mid] - target_clock) < abs(closest - target_clock):
closest = clock_list[mid]
return closest
def calculate_divisor(clock_need, clock_list, min_divisor=6):
is_perfect = True
for i in clock_list:
for j in range(0, 255):
if (clock_need * j) == i:
closest_clock = i
divisor = j
return closest_clock, divisor, is_perfect
is_perfect = False
closest_clock = find_closest_clock(clock_need, clock_list)
if closest_clock == 0:
return None, None, None
divisor = closest_clock // clock_need
if divisor < min_divisor:
min_diff = float('inf')
best_clock = None
for clock in clock_list:
if clock >= clock_need * min_divisor:
current_divisor = clock // clock_need
if current_divisor < min_divisor:
continue
diff = abs(clock - clock_need * current_divisor)
if diff < min_diff:
min_diff = diff
best_clock = clock
if best_clock is not None:
return best_clock, best_clock // clock_need, is_perfect
return closest_clock, divisor, is_perfect
clock_list = [
408, 420, 432, 444, 456, 468, 480, 492, 504, 516, 528, 540, 552, 564,
576, 588, 600, 612, 624, 636, 648, 660, 672, 684, 696, 708, 720, 732,
744, 756, 768, 780, 792, 804, 816, 828, 840, 852, 864, 876, 888, 900,
912, 924, 936, 948, 960, 972, 984, 996, 1008, 1020, 1032, 1044, 1056,
1068, 1080, 1092, 1104, 1116, 1128, 1140, 1152, 1164, 1176, 1188, 1200,
1212, 1224, 1236, 1248, 1260, 1272, 1284, 1296, 1308, 1320, 1332, 1344,
1356, 1368, 1380, 1392, 1404, 1416, 1428, 1440, 1452, 1464, 1476, 1488,
1500, 1512, 1524, 1536, 1548, 1560, 1572, 1584, 1596, 1608, 1620, 1632,
1644, 1656, 1668, 1680, 1692
]
clock_need = int(input("请输入需要的时钟(MHz): "))
closest_clock, divisor, is_perfect = calculate_divisor(clock_need, clock_list)
if is_perfect:
print(f"父时钟: {closest_clock}MHz, 分频系数: {divisor}, 分频后的频率: {closest_clock / divisor}MHz")
else:
print(f"无法找到完美，最近的父时钟: {closest_clock}, 分频系数: {divisor}, 分频后的频率: {closest_clock / divisor}MHz")
print("请修改分频系数表 clk_tbl 中 HV 分频系数为: {LCD_IF_HV, " + hex(divisor) + ", 1, 1, 0}")
第一次编译时候请取消勾选 mpp sample smartIPC_demo 编译完成一次之后使用 cleanmpp && mkmpp 来编译mpp相关demo。
@yimu163com 在 R329代码里找不到BOOT0启动打印“HELLO! BOOT0 is starting!” 中说：
Binary file ./device/config/chips/r329/bin/boot0_nand_sun50iw11p1.bin matches
Binary file ./device/config/chips/r329/bin/sboot_sun50iw11p1.bin matches
Binary file ./device/config/chips/r329/bin/boot0_spinor_sun50iw11p1.bin matches
Binary file ./device/config/chips/r329/bin/boot0_sdcard_sun50iw11p1.bin matches
在这几个bin里，BOOT0不开源
DSI
dsi1_backlight: backlight0 {
compatible = "pwm-backlight";
status = "okay";
brightness-levels = <
0 1 2 3 4 5 6 7
8 9 10 11 12 13 14 15
16 17 18 19 20 21 22 23
24 25 26 27 28 29 30 31
32 33 34 35 36 37 38 39
40 41 42 43 44 45 46 47
48 49 50 51 52 53 54 55
56 57 58 59 60 61 62 63
64 65 66 67 68 69 70 71
72 73 74 75 76 77 78 79
80 81 82 83 84 85 86 87
88 89 90 91 92 93 94 95
96 97 98 99 100 101 102 103
104 105 106 107 108 109 110 111
112 113 114 115 116 117 118 119
120 121 122 123 124 125 126 127
128 129 130 131 132 133 134 135
136 137 138 139 140 141 142 143
144 145 146 147 148 149 150 151
152 153 154 155 156 157 158 159
160 161 162 163 164 165 166 167
168 169 170 171 172 173 174 175
176 177 178 179 180 181 182 183
184 185 186 187 188 189 190 191
192 193 194 195 196 197 198 199
200 201 202 203 204 205 206 207
208 209 210 211 212 213 214 215
216 217 218 219 220 221 222 223
224 225 226 227 228 229 230 231
232 233 234 235 236 237 238 239
240 241 242 243 244 245 246 247
248 249 250 251 252 253 254 255>;
default-brightness-level = <200>;
enable-gpios = <&pio PH 18 GPIO_ACTIVE_HIGH>;
pwms = <&pwm0 0 50000 0>;
};
&de {
chn_cfg_mode = <3>;
status = "okay";
};
&vo0 {
status = "okay";
};
&dlcd1 {
status = "okay";
};
&dsi1 {
status = "okay";
pinctrl-0 = <&dsi1_4lane_pins_a>;
pinctrl-1 = <&dsi1_4lane_pins_b>;
pinctrl-names = "active","sleep";
ports {
dsi1_out: port@1{
reg = <1>;
dsi_out_panel: endpoint {
remote-endpoint = <&panel_in>;
};
};
};
panel: panel@0 {
compatible = "panel-dsi";
status = "okay";
reg = <0>;
power0-supply = <®_cldo4>;
power1-supply = <®_cldo1>;
reset-gpios = <&pio PD 22 GPIO_ACTIVE_HIGH>; //reset
backlight = <&dsi1_backlight>;
dsi,flags = <MIPI_DSI_MODE_VIDEO>;
dsi,lanes = <4>;
dsi,format = <0>;
panel-init-sequence = [
15 00 02 E0 00
15 00 02 E1 93
15 00 02 E2 65
15 00 02 E3 F8
15 00 02 80 03
15 00 02 E0 01
15 00 02 00 00
15 00 02 01 25
15 00 02 03 00
15 00 02 04 30
15 00 02 0C 74
15 00 02 17 00
15 00 02 18 C7
15 00 02 19 01
15 00 02 1A 00
15 00 02 1B C7
15 00 02 1C 01
15 00 02 24 FE
15 00 02 37 19
15 00 02 35 28
15 00 02 38 05
15 00 02 39 08
15 00 02 3A 12
15 00 02 3C 7E
15 00 02 3D FF
15 00 02 3E FF
15 00 02 3F 7F
15 00 02 40 06
15 00 02 41 A0
15 00 02 43 1E
15 00 02 44 0B
15 00 02 55 02
15 00 02 57 6A
15 00 02 59 0A
15 00 02 5A 2E
15 00 02 5B 1A
15 00 02 5C 15
15 00 02 5D 7F
15 00 02 5E 61
15 00 02 5F 50
15 00 02 60 43
15 00 02 61 3F
15 00 02 62 32
15 00 02 63 35
15 00 02 64 1F
15 00 02 65 38
15 00 02 66 36
15 00 02 67 36
15 00 02 68 54
15 00 02 69 42
15 00 02 6A 48
15 00 02 6B 39
15 00 02 6C 34
15 00 02 6D 26
15 00 02 6E 14
15 00 02 6F 02
15 00 02 70 7F
15 00 02 71 61
15 00 02 72 50
15 00 02 73 43
15 00 02 74 3F
15 00 02 75 32
15 00 02 76 35
15 00 02 77 1F
15 00 02 78 38
15 00 02 79 36
15 00 02 7A 36
15 00 02 7B 54
15 00 02 7C 42
15 00 02 7D 48
15 00 02 7E 39
15 00 02 7F 34
15 00 02 80 26
15 00 02 81 14
15 00 02 82 02
15 00 02 E0 02
15 00 02 00 52
15 00 02 01 5F
15 00 02 02 5F
15 00 02 03 50
15 00 02 04 77
15 00 02 05 57
15 00 02 06 5F
15 00 02 07 4E
15 00 02 08 4C
15 00 02 09 5F
15 00 02 0A 4A
15 00 02 0B 48
15 00 02 0C 5F
15 00 02 0D 46
15 00 02 0E 44
15 00 02 0F 40
15 00 02 10 5F
15 00 02 11 5F
15 00 02 12 5F
15 00 02 13 5F
15 00 02 14 5F
15 00 02 15 5F
15 00 02 16 53
15 00 02 17 5F
15 00 02 18 5F
15 00 02 19 51
15 00 02 1A 77
15 00 02 1B 57
15 00 02 1C 5F
15 00 02 1D 4F
15 00 02 1E 4D
15 00 02 1F 5F
15 00 02 20 4B
15 00 02 21 49
15 00 02 22 5F
15 00 02 23 47
15 00 02 24 45
15 00 02 25 41
15 00 02 26 5F
15 00 02 27 5F
15 00 02 28 5F
15 00 02 29 5F
15 00 02 2A 5F
15 00 02 2B 5F
15 00 02 2C 13
15 00 02 2D 1F
15 00 02 2E 1F
15 00 02 2F 01
15 00 02 30 17
15 00 02 31 17
15 00 02 32 1F
15 00 02 33 0D
15 00 02 34 0F
15 00 02 35 1F
15 00 02 36 05
15 00 02 37 07
15 00 02 38 1F
15 00 02 39 09
15 00 02 3A 0B
15 00 02 3B 11
15 00 02 3C 1F
15 00 02 3D 1F
15 00 02 3E 1F
15 00 02 3F 1F
15 00 02 40 1F
15 00 02 41 1F
15 00 02 42 12
15 00 02 43 1F
15 00 02 44 1F
15 00 02 45 00
15 00 02 46 17
15 00 02 47 17
15 00 02 48 1F
15 00 02 49 0C
15 00 02 4A 0E
15 00 02 4B 1F
15 00 02 4C 04
15 00 02 4D 06
15 00 02 4E 1F
15 00 02 4F 08
15 00 02 50 0A
15 00 02 51 10
15 00 02 52 1F
15 00 02 53 1F
15 00 02 54 1F
15 00 02 55 1F
15 00 02 56 1F
15 00 02 57 1F
15 00 02 58 40
15 00 02 5B 10
15 00 02 5C 06
15 00 02 5D 40
15 00 02 5E 00
15 00 02 5F 00
15 00 02 60 40
15 00 02 61 03
15 00 02 62 04
15 00 02 63 6C
15 00 02 64 6C
15 00 02 65 75
15 00 02 66 08
15 00 02 67 B4
15 00 02 68 08
15 00 02 69 6C
15 00 02 6A 6C
15 00 02 6B 0C
15 00 02 6D 00
15 00 02 6E 00
15 00 02 6F 88
15 00 02 75 BB
15 00 02 76 00
15 00 02 77 05
15 00 02 78 2A
15 00 02 E0 04
15 00 02 37 58
15 00 02 00 0E
15 00 02 02 B3
15 00 02 09 61
15 00 02 0E 48
15 00 02 E0 00
05 32 01 11
05 05 01 29
15 32 02 35 00
];
panel-exit-sequence = [
05 14 01 28
05 50 01 10
];
display-timings {
native-mode = <&dsi1_timing0>;
dsi1_timing0: timing0 {
clock-frequency = <68215200>;
hback-porch = <20>;
hactive = <800>;
hfront-porch = <20>;
hsync-len = <20>;
vback-porch = <8>;
vactive = <1280>;
vfront-porch = <30>;
vsync-len = <4>;
};
};
port {
panel_in: endpoint {
remote-endpoint = <&dsi_out_panel>;
};
};
};
};
&dsi0combophy {
status = "disabled";
};
&dsi1combophy {
status = "okay";
};target/allwinner/t113-nezha/base-files
target/allwinner/t113-nezha/busybox-init-base-files
根据选择的overlay方式而定
@scanli 请问设备是否刷写过安全启动？如果没有刷写过但是出现这个情况可以做以下临时修改
在 device/config/chips/t113_i/configs/default/ 修改 boot_package.cfg 删除 optee.fex 行
在 lichee/linux-5.4/arch/arm/boot/dts/sun8iw20p1.dtsi 中注释
psci {
compatible = "arm,psci-1.0";
method = "smc";
};
前往 lichee/linux-5.4/arch/arm/mach-sunxi/platsmp.c 加入
static int sun8i_t113_smp_boot_secondary(unsigned int cpu,
struct task_struct *idle)
{
u32 reg;
void __iomem *cpucfg_membase = ioremap(0x09010000, 0x10);
void __iomem *cpuexec_membase[] = {ioremap(0x070005C4, 0x10),ioremap(0x070005C8, 0x10)};
if (cpu != 1)
return 0;
spin_lock(&cpu_lock);
writel(__pa_symbol(secondary_startup), cpuexec_membase[cpu]);
reg = readl(cpucfg_membase);
writel(reg | BIT(cpu), cpucfg_membase);
spin_unlock(&cpu_lock);
return 0;
}
static const struct smp_operations sun8i_t113_smp_ops __initconst = {
.smp_boot_secondary = sun8i_t113_smp_boot_secondary,
};
CPU_METHOD_OF_DECLARE(sun8i_t113_smp, "allwinner,sun8iw20p1", &sun8i_t113_smp_ops);
注意这只是临时修改跳过检查，之后最好使用创龙提供的虚拟机复现看看会不会也出现这个问题
DE和RO为使能管脚。DE为低电平、RE为低电平时为接收；DE为高电平、RE为高电平时为发送；RO和DI为数据管脚。RO为接收，DI为发送；因此我们经常将DE和RE直接连接，用一个IO口控制。
需要添加以下三个成员：
示例：
uart1: uart@2500400 {
...
status = "okay";
//添加以下三行
sunxi,uart-rs485 = <1>;
sunxi,uart-485fl = <1>;
sunxi,uart-485oe-gpios = <&pio PG 8 GPIO_ACTIVE_HIGH>;
};
A40I 5.10 内核：
uart5_pins_a: uart5_pins@0 {
pins = "PH6", "PH7";
function = "uart5";
};
uart5_pins_b: uart5_pins@1 {
pins = "PH6", "PH7";
function = "gpio_in";
};
&uart5 {
pinctrl-names = "default", "sleep";
pinctrl-0 = <&uart5_pins_a>;
pinctrl-1 = <&uart5_pins_b>;
rs485-enable = <0>;
rs485-mode = <0>; /* defalut 0:rx 1:tx */
rs485-mode-pin = <&pio PH 8 GPIO_ACTIVE_LOW>;
status = "disabled";
};
mboot，mkernel是编译boot和内核的，并没有编译rootfs，如果已经编译好了rootfs则可以代替，如果没有编译rootfs则需要make来编译rootfs
make distclean后删除out文件夹重新编译看看
@maplerian 开启外部DCDC, POWERTCTL会自动关闭APP_LDO，这个是一个硬件行为
@maplerian 在深度休眠下，内部APP_LDO由PWRCTRL硬件关闭，且深度休眠下GPIO控制器断电不会启用DCDC，唤醒时由PWRCTRL硬件逻辑开启内部APP_LDO，然后启用GPIO控制器拉高启用外部DCDC，启用后自动切换到外部DCDC供电
APP_LDO的关闭是PWRCTRL的硬件行为，由配置处理器deep sleep mode后，CPU进入WFI触发PWRCTRL的该行为，无寄存器配置。PWRCTRL仅支持手动关闭DSP。外挂DCDC可以通过读取LDO_EN寄存器查看目前是否开启内部LDO
@chrisvista 如果配置UART适配8250规范则是AS0，如果是sunxi-uart规范则是S0
测试 AWOL 开源的 Tina SDK + T113-S3 板子，hciattach -n ttyS1 xradio 正常
“sunxi_ledc_irq_handler()1313 - wait time is more than 600000 ns,going to reset ledc and drop this operation!”
看代码，此打印的意思是ledc传输数据后超过600ms才进入中断处理，看上去是被别的高优先级中断抢占
Makefile:68: *** missing separator. Stop.
这个错误通常表示在 Makefile 的第 68 行或附近存在语法错误。Makefile 中使用的规则必须遵循严格的缩进规范，通常是使用 Tab 键进行缩进，而不是空格。
请检查 Makefile 第 68 行附近的代码，确保每个规则的命令部分都以 Tab 键开头，并且规则名称和命令之间使用冒号（:）分隔。此外，还需要确认 Makefile 的每一行都是使用相同的缩进方式，要么都是 Tab，要么都是空格，不要混用。
默认HDMI不开，需要命令开启
cd /sys/kernel/debug/dispdbg
echo disp0 > name; echo switch1 > command; echo 4 10 0 0 0x4 0x101 0 0 0 8 > param; echo 1 > start;
RI-2020.5-linux 编译器需要向购买开发板的商家/代理提交申请，需要提供自己的HIFI5 DSP Xtensa Xplorer的证明
@damiaa 现在是新版本平台了，直接拿awol账号下载，免去再注册一个平台的麻烦：https://d1.docs.aw-ol.com/study/study_3getsdktoc/
@zifeiyu 那为什么pack打包到固件的有，刷进去就没了，是不是刷写到emmc但是TF卡启动了？
@zifeiyu 那你得检查下是不是刷错固件了，或者没有运行pack命令刷的还是老版本
@zifeiyu 那看一下合成的dts的uart情况，out/t113-100ask/image/.sunxi.dts
也可以看一下 out/t113-100ask/image/.sunxi.dts 文件的
@zifeiyu uboot阶段fdt print看看有没有okay，另外图没发上来
检查使用的SDK是哪一个版本，目前awol的Tina 5.0不支持sample_rtsp，这个demo适配的是Tina 4.0，需要向代理获取支持
@wj8331585 支持，出现段错误可以编译一个gdb进去看看哪里错了
测试代码：
w = 1920;
h = 1080;
bpp = 32;
SDL_Init( SDL_INIT_EVERYTHING );
SDL_SetVideoMode( w,h, bpp, SDL_HWSURFACE|SDL_DOUBLEBUF );@alb702 add your layer and cat that file see what layer you configured
AP的数据是在 lwip 的 static struct etharp_entry arp_table[ARP_TABLE_SIZE]; 中维护
#if LWIP_XR_IMPL
ip4_addr_t* etharp_get_ip_from_mac(struct eth_addr *ethaddr) {
int i;
ip4_addr_t* ip_ret = NULL;
LWIP_ASSERT("ethaddr != NULL", ethaddr != NULL);
for (i = 0; i < ARP_TABLE_SIZE; i++) {
if (memcmp(ethaddr, &arp_table[i].ethaddr, sizeof(struct eth_addr)) == 0) {
ip_ret = &arp_table[i].ipaddr;
break;
}
}
return ip_ret;
}
#endif
@alb702 try to cat /sys/class/disp/disp/attr/sys
empty:
root@TinaLinux:/# cat /sys/class/disp/disp/attr/sys
screen 0:
de_rate 300000000 hz, ref_fps:62
mgr0: 800x1280 fmt[rgb] cs[0x204] range[full] eotf[0x4] bits[8bits] err[0] force_sync[0] unblank direct_show[false] iommu[1]
dmabuf: cache[0] cache max[0] umap skip[0] umap skip max[52]
lcd output backlight(100) fps:62.1 800x1280
err:0 skip:228 irq:2786 vsync:0 vsync_skip:0
BUF enable ch[1] lyr[0] z[16] prem[N] a[pixel 255] fmt[ 0] fb[ 800,1280; 800,1280; 800,1280] crop[ 0, 0, 800,1280] frame[ 0, 0, 800,1280] addr[ff800000, 0, 0] flags[0x 0] trd[0,0] depth[ 0]
add layer
cat /sys/class/disp/disp/attr/sys
screen 0:
de_rate 300000000 hz, ref_fps:62
mgr0: 800x1280 fmt[rgb] cs[0x204] range[full] eotf[0x4] bits[8bits] err[0] force_sync[0] unblank direct_show[false] iommu[1]
dmabuf: cache[0] cache max[0] umap skip[0] umap skip max[52]
lcd output backlight(100) fps:62.1 800x1280
err:933 skip:228 irq:6815 vsync:0 vsync_skip:0
COLOR enable ch[0] lyr[0] z[16] prem[N] a[pixel 0] fmt[ 0] fb[ 0, 0; 0, 0; 0, 0] crop[ 0, 0, 200,1280] frame[ 0, 0, 200,1280] addr[ffff0000, 0, 0] flags[0x 0] trd[0,0]
depth[ 0] COLOR enable ch[0] lyr[1] z[16] prem[N] a[pixel 0] fmt[ 0] fb[ 0, 0; 0, 0; 0, 0] crop[ 200, 0, 200,1280] frame[ 200, 0, 200,1280] addr[ff00ff00, 0, 0] flags[0x 0] trd[0,0]
depth[ 0] COLOR enable ch[0] lyr[2] z[16] prem[N] a[pixel 0] fmt[ 0] fb[ 0, 0; 0, 0; 0, 0] crop[ 400, 0, 200,1280] frame[ 400, 0, 200,1280] addr[ff0000ff, 0, 0] flags[0x 0] trd[0,0]
depth[ 0] COLOR enable ch[0] lyr[3] z[16] prem[N] a[pixel 0] fmt[ 0] fb[ 0, 0; 0, 0; 0, 0] crop[ 600, 0, 200,1280] frame[ 600, 0, 200,1280] addr[ffffff00, 0, 0] flags[0x 0] trd[0,0]
depth[ 0] BUF enable ch[1] lyr[0] z[16] prem[N] a[pixel 255] fmt[ 0] fb[ 800,1280; 800,1280; 800,1280] crop[ 0, 0, 800,1280] frame[ 0, 0, 800,1280] addr[ff800000, 0, 0] flags[0x 0] trd[0,0]
depth[ 0]
@fleieng 如果烧录了eFuse会写eFuse标志位，就是eFuse选择，如果没烧eFuse，则是GPIO选择，芯片出厂默认是GPIO选择
try to use english to describe, the translate I can't understand.
package/allwinner/tina_multimedia/tplayer/configs/t113_linux_cedarx.conf
检查是否使用 video lbc mode, is_lossy and rc_en
如果配置了设置 0 0 0
########### paramter ############
[paramter]
start_play_cache_video_frame_num = 4
start_play_cache_size = 8 # KB
cache_buffer_size = 10240 # KB
cache_buffer_size_live = 10240 # KB
start_play_cache_time = 5 # Second
max_start_play_chache_size = 512 # KB
max_cache_buffer_size = 10240 # KB
max_http_stream_buf_size = 2048 #KB
# the number of audio stream cached before decoding.
max_audio_stream_frame_num = 128
# see comment in player.cpp
av_sync_duration = 0 # millisecond
# picture num for modules
pic_4list_num = 2
pic_4di_num = 0
pic_4rotate_num = 0
pic_4smooth_num = 2
# picture format: mb32/nv21/nv12/nv
# deinterlace format
deinterlace_fmt = nv12
# video decoder output picture format
vd_output_fmt = nv21
# video lbc mode, is_lossy and rc_en
vd_lbc_mode = 2
vd_lbc_is_lossy = 1
vd_lbc_rc_en = 0
# gpu align stride values: 16/32
# mali 400mp2 32bit
gpu_align_bitwidth = 32
# if value 1 : send 3-frames black-pic to GPU
# SP: switch Program
#black_pic_4_SP = 0
# compensate for av vsync
compensate_vsync = 4
#use transform module to rotate the video. notice:only r18/r58/r40 support transform module
tr_rotate_flag = 0 #1 means rotate,0 means not rotate
tr_rotate_degree = 0 #0 means the degree is 0, 90 means the degree is 90,180 means the degree is 180, 270 means the degree is 270
#use g2d module to rotate the video. notice:F133/R528
g2d_rotate_degree = 0
#the max width and height of video in this product,which need align 64
hold_last_picture_with = 1920
hold_last_picture_height = 1088
#The first frame decoded will be used for quick display.
show_1th_frame_quick = 1
# log will output if level >= log_level
#VERBOSE = 2,
#DEBUG = 3,
#INFO = 4,
#WARNING = 5,
#ERROR = 6,
log_level = 6
# define platform for ve phy addr offset
platform = t113
# scaledown large video(>=1080p) or not,0:means not scaledown,1:means scaledown
scaledown_large_video_flag = 0
#use ion buf in streamManager.c , 0:means not use ion buf,1:means use ion buf
use_ion_buf_flag = 0
########### plugin ##############
# 1. audio decoder plugin
[adecoder-0]
comment = aac_adecoder
id = adecoder.aac
lib = libaw_aacdec.so
[adecoder-1]
comment = alac_adecoder
id = adecoder.alac
lib = libaw_alacdec.so
[adecoder-2]
comment = amr_adecoder
id = adecoder.amr
lib = libaw_amrdec.so
[adecoder-3]
comment = ape_adecoder
id = adecoder.ape
lib = libaw_apedec.so
[adecoder-4]
comment = flac_adecoder
id = adecoder.flac
lib = libaw_flacdec.so
[adecoder-5]
comment = mp3_adecoder
id = adecoder.mp3
lib = libaw_mp3dec.so
[adecoder-6]
comment = ogg_adecoder
id = adecoder.ogg
lib = libaw_oggdec.so
[adecoder-7]
comment = wav_adecoder
id = adecoder.wav
lib = libaw_wavdec.so
[adecoder-8]
comment = atrc_adecoder
id = adecoder.atrc
lib = libaw_atrcdec.so
[adecoder-9]
comment = ra_adecoder
id = adecoder.ra
lib = libaw_radec.so
[adecoder-10]
comment = dsd_adecoder
id = adecoder.dsd
lib = libaw_dsddec.so
[adecoder-11]
comment = g729_adecoder
id = adecoder.g729
lib = libaw_g729dec.so
[adecoder-12]
comment = opus_adecoder
id = adecoder.opus
lib = libaw_opusdec.so
# 2. video decoder plugin
[vdecoder-0]
comment = h264_vdecoder
id = vdecoder.h264
lib = libawh264.so
init = CedarPluginVDInit
[vdecoder-1]
comment = mjpeg_vdecoder
id = vdecoder.mjpeg
lib = libawmjpeg.so
init = CedarPluginVDInit
[vdecoder-2]
comment = mpeg2_vdecoder
id = vdecoder.mpeg2
lib = libawmpeg2.so
init = CedarPluginVDInit
[vdecoder-3]
comment = mpeg4base_vdecoder
id = vdecoder.mpeg4base
lib = libawmpeg4base.so
init = CedarPluginVDInit
[vdecoder-4]
comment = mpeg4dx_vdecoder
id = vdecoder.mpeg4dx
lib = libawmpeg4dx.so
init = CedarPluginVDInit
reference = vdecoder.mpeg4base
[vdecoder-5]
comment = mpeg4h263_vdecoder
id = vdecoder.mpeg4h263
lib = libawmpeg4h263.so
init = CedarPluginVDInit
reference = vdecoder.mpeg4base
[vdecoder-6]
comment = mpeg4normal_vdecoder
id = vdecoder.mpeg4normal
lib = libawmpeg4normal.so
init = CedarPluginVDInit
reference = vdecoder.mpeg4base
[vdecoder-7]
comment = wmv3_vdecoder
id = vdecoder.wmv3
lib = libawwmv3.so
init = CedarPluginVDInit
[vdecoder-8]
comment = h265_vdecoder
id = vdecoder.h265
lib = libawh265.so
init = CedarPluginVDInit
# 3. external plugin
#[plugin-0]
#comment = rtp_plugin
#id = rtp
#lib = librtp.so
检查一下modules的配置
define KernelPackage/net-broadcom
SUBMENU:=$(WIRELESS_MENU)
DEPENDS:= +ap6256-firmware +@PACKAGE_broadcom-rftest
TITLE:=broadcom(ap6256...) support
FILES:=$(LINUX_DIR)/drivers/net/wireless/bcmdhd/bcmdhd.ko
KCONFIG:=\
CONFIG_BCMDHD=m \
CONFIG_BCMDHD_SDIO=y \
CONFIG_BCMDHD_OOB=y \
CONFIG_BCMDHD_FW_PATH="/etc/firmware/fw_bcmdhd.bin" \
CONFIG_BCMDHD_NVRAM_PATH="/etc/firmware/nvram.txt" \
CONFIG_BCMDHD_SDIO=y \
CONFIG_SUNXI_RFKILL=y \
CONFIG_MMC=y \
CONFIG_PWRSEQ_EMMC=y \
CONFIG_PWRSEQ_SIMPLE=y \
CONFIG_MMC_SUNXI=y \
CONFIG_MMC_SUNXI_V4P1X=y \
CONFIG_MMC_SUNXI_V4P00X=y \
CONFIG_MMC_SUNXI_V4P10X=y \
CONFIG_MMC_SUNXI_V4P5X=y \
CONFIG_MMC_SUNXI_V5P3X=y \
AUTOLOAD:=$(call AutoProbe,bcmdhd,1)
endef
define KernelPackage/net-broadcom/description
Kernel modules for Broadcom AP6256... support
endef
$(eval $(call KernelPackage,net-broadcom))
使用dma模式搬运数据，需要打上如下补丁：
ledc在dma模式的代码存在问题，已修复该问题，ledc的dma通道之前也没有支持，需要添加上
diff --git a/hal/source/dma/platform/dma-sun8iw20.h b/hal/source/dma/platform/dma-sun8iw20.h
index 2140014..fc5c72e 100644
--- a/hal/source/dma/platform/dma-sun8iw20.h
+++ b/hal/source/dma/platform/dma-sun8iw20.h
@@ -136,6 +136,7 @@
#define DRQDST_OTG_EP3 32
#define DRQDST_OTG_EP4 33
#define DRQDST_OTG_EP5 34
+#define DRQDST_LEDC 42
#define DRQDST_TWI0_TX 43
#define DRQDST_TWI1_TX 44
#define DRQDST_TWI2_TX 45
diff --git a/hal/source/ledc/hal_ledc.c b/hal/source/ledc/hal_ledc.c
index 5499452..ddf471f 100755
--- a/hal/source/ledc/hal_ledc.c
+++ b/hal/source/ledc/hal_ledc.c
@@ -20,9 +20,10 @@
#define led_err(fmt, args...) printf("%s()%d - "fmt, __func__, __LINE__, ##args)
#define LEDC_PIN_SLEEP 0
+#define LEDC_DMA_BUF_SIZE 4096
struct ledc_config ledc_config = {
- .led_count = 3,
+ .led_count = 1024,
.reset_ns = 84,
.t1h_ns = 800,
.t1l_ns = 450,
@@ -37,6 +38,7 @@
static unsigned long base_addr = LEDC_BASE;
struct sunxi_dma_chan *dma_chan;
struct sunxi_led *led;
+static uint8_t already_init;
static hal_irqreturn_t sunxi_ledc_irq_handler(void *dummy)
{
@@ -448,15 +450,16 @@
void hal_ledc_dma_callback(void *para)
{
- printf("dma callback\n");
+ ledc_info("dma transfer end\n");
}
-void hal_ledc_trans_data(struct ledc_config *ledc)
+int hal_ledc_trans_data(struct ledc_config *ledc)
{
- int i;
+ int i, ret;
unsigned long int size;
unsigned int mask = 0;
struct dma_slave_config slave_config;
+ unsigned int const *buf = ledc->data;
mask = LEDC_TRANS_FINISH_INT_EN | LEDC_WAITDATA_TIMEOUT_INT_EN
| LEDC_FIFO_OVERFLOW_INT_EN | LEDC_GLOBAL_INT_EN;
@@ -480,23 +483,32 @@
ledc_reset_en();
size = ledc->length * 4;
+ if (size <= LEDC_DMA_BUF_SIZE) {
+ memcpy(ledc->align_dma_buf, buf, ledc->length);
+ buf = ledc->align_dma_buf;
+ }
- hal_dcache_clean((unsigned long)ledc->data, sizeof(ledc->data));
+ hal_dcache_clean((unsigned long)buf, size);
slave_config.direction = DMA_MEM_TO_DEV;
- slave_config.src_addr = (unsigned long)(ledc->data);
+ slave_config.src_addr = (unsigned long)buf;
slave_config.dst_addr = (uint32_t)(base_addr + LEDC_DATA_REG);
slave_config.src_addr_width = DMA_SLAVE_BUSWIDTH_4_BYTES;
slave_config.dst_addr_width = DMA_SLAVE_BUSWIDTH_4_BYTES;
- slave_config.src_maxburst = DMA_SLAVE_BURST_16;
- slave_config.dst_maxburst = DMA_SLAVE_BURST_16;
+ slave_config.src_maxburst = DMA_SLAVE_BURST_4;
+ slave_config.dst_maxburst = DMA_SLAVE_BURST_4;
slave_config.slave_id = sunxi_slave_id(DRQDST_LEDC, DRQSRC_SDRAM);
- hal_dma_slave_config(dma_chan, &slave_config);
+ ret = hal_dma_slave_config(dma_chan, &slave_config);
+ if (ret) {
+ led_err("dma slave config failed\n");
+ return -1;
+ }
- hal_dma_prep_device(dma_chan, slave_config.dst_addr, slave_config.src_addr, size, DMA_MEM_TO_DEV);
-
- //dma_chan->callback = ledc_dma_callback;
- hal_dma_start(dma_chan);
+ ret = hal_dma_prep_device(dma_chan, slave_config.dst_addr, slave_config.src_addr, size, DMA_MEM_TO_DEV);
+ if (ret) {
+ led_err("dma prep device failed\n");
+ return -1;
+ }
hal_ledc_set_time(ledc);
ledc_set_output_mode(ledc->output_mode);
@@ -504,7 +516,15 @@
ledc_set_dma_mode();
ledc_enable_irq(mask);
ledc_enable();
+
+ dma_chan->callback = hal_ledc_dma_callback;
+ ret = hal_dma_start(dma_chan);
+ if (ret) {
+ led_err("dma start trans failed\n");
+ return -1;
+ }
}
+ return 0;
}
void hal_ledc_clear_all_irq(void)
@@ -598,6 +618,14 @@
int hal_ledc_init(void)
{
+ if (already_init) {
+ already_init++;
+ ledc_info("ledc has been inited, return ok\n");
+ return 0;
+ }
+
+ int ret, i;
+
ledc_info("hal_led_init\n");
led = malloc(sizeof(struct sunxi_led));
@@ -611,25 +639,40 @@
led->config.data = malloc(sizeof(unsigned int) * led->config.led_count);
if (NULL == led->config.data) {
led_err("sunxi led config data malloc err\n");
- goto err1;
+ goto err0;
}
+ for(i = 0;i < led->config.led_count;i++)
+ led->config.data[i] = 0;
if (ledc_clk_init())
{
led_err("ledc clk init failed \n");
+ goto err1;
}
if (ledc_pinctrl_init())
{
led_err("ledc pinctrl init failed \n");
+ goto err2;
}
- hal_dma_chan_request(&dma_chan);
+ ret = hal_dma_chan_request(&dma_chan);
+ if (ret == HAL_DMA_CHAN_STATUS_BUSY)
+ {
+ led_err("request dma_chan failed\n");
+ goto err3;
+ }
+ led->config.align_dma_buf = dma_alloc_coherent(LEDC_DMA_BUF_SIZE);
+ if (!led->config.align_dma_buf)
+ {
+ led_err("alloc dma memory failed\n");
+ goto err4;
+ }
if (hal_request_irq(SUNXI_IRQ_LEDC, sunxi_ledc_irq_handler, "ledc", led) < 0)
{
led_err("ledc request irq failed \n");
- goto errirq;
+ goto err5;
}
hal_enable_irq(SUNXI_IRQ_LEDC);
@@ -638,13 +681,22 @@
pm_devops_register(&pm_ledc);
#endif
+ already_init++;
ledc_info("hal_led_init success\n");
return 0;
-errirq:
- free(led->config.data);
+err5:
+ dma_free_coherent(led->config.align_dma_buf);
+err4:
+ hal_dma_chan_free(dma_chan);
+err3:
+ ledc_pinctrl_exit();
+err2:
+ ledc_clk_exit();
err1:
+ free(led->config.data);
+err0:
free(led);
return -1;
@@ -652,27 +704,35 @@
void hal_ledc_deinit(void)
{
+ if (already_init > 0) {
+ if (--already_init == 0) {
#ifdef CONFIG_COMPONENTS_PM
- pm_devops_unregister(&pm_ledc);
+ pm_devops_unregister(&pm_ledc);
#endif
- hal_disable_irq(SUNXI_IRQ_LEDC);
- hal_free_irq(SUNXI_IRQ_LEDC);
- hal_dma_chan_free(dma_chan);
- ledc_pinctrl_exit();
- ledc_clk_exit();
- free(led->config.data);
- free(led);
+ hal_disable_irq(SUNXI_IRQ_LEDC);
+ hal_free_irq(SUNXI_IRQ_LEDC);
+ dma_free_coherent(led->config.align_dma_buf);
+ hal_dma_chan_free(dma_chan);
+ ledc_pinctrl_exit();
+ ledc_clk_exit();
+ free(led->config.data);
+ free(led);
+ }
+ }
}
int sunxi_set_all_led(unsigned int brightness)
{
- int i;
+ int i, ret;
led->config.length = led->config.led_count;
for(i = 0;i < led->config.led_count;i++)
led->config.data[i] = brightness;
- hal_ledc_trans_data(&led->config);
+ ret = hal_ledc_trans_data(&led->config);
+ if (ret) {
+ led_err("ledc trans data error\n");
+ }
return 0;
}
@@ -680,6 +740,7 @@
int sunxi_set_led_brightness(int led_num, unsigned int brightness)
{
u32 reg_val;
+ int i, ret;
if (NULL == led) {
led_err("err : ledc is not init\n");
@@ -691,10 +752,16 @@
return -1;
}
- led->config.length = 1;
+ led->config.length = led_num;
led->config.data[led_num-1] = brightness;
- hal_ledc_trans_data(&led->config);
+ for (i = 0; i < led_num; i++)
+ ledc_info("the %d led light is %u\n", i + 1, led->config.data[i]);
+
+ ret = hal_ledc_trans_data(&led->config);
+ if (ret) {
+ led_err("ledc trans data error\n");
+ }
reg_val = hal_ledc_get_irq_status();
ledc_info("ledc interrupt status reg is %x", reg_val);
diff --git a/hal/source/ledc/platform_ledc.h b/hal/source/ledc/platform_ledc.h
index 39f6933..2fa9c38 100644
--- a/hal/source/ledc/platform_ledc.h
+++ b/hal/source/ledc/platform_ledc.h
@@ -33,8 +33,6 @@
#ifndef __PLATFORM_LEDC_H__
#define __PLATFORM_LEDC_H__
-#define DRQDST_LEDC 43
-
#if defined(CONFIG_ARCH_SUN8IW18P1)
#include "platform/ledc_sun8iw18.h"
#endif
diff --git a/hal/test/ledc/test_ledc.c b/hal/test/ledc/test_ledc.c
index 1ade796..79694c0 100755
--- a/hal/test/ledc/test_ledc.c
+++ b/hal/test/ledc/test_ledc.c
@@ -20,6 +20,7 @@
int ledc_test(int argc, char **argv)
{
int brightness = 0;
+ int led_num;
printf("========LEDC TEST========\n");
@@ -32,9 +33,14 @@
return 0;
}
- brightness = atoi(argv[2]);
+ led_num = atoi(argv[1]);
+ if (led_num < 1 || led_num > 1024)
+ {
+ printf("The led_num you entered should be between 1 and 1024\n");
+ }
+ brightness = atoi(argv[3]);
- switch(argv[1][0])
+ switch(argv[2][0])
{
case 'R' : brightness <<= 8; break;
case 'G' : brightness <<= 16; break;
@@ -43,7 +49,8 @@
return -1;
}
- sunxi_set_led_brightness(1, brightness);
+ sunxi_set_led_brightness(led_num, brightness);
+ printf("led is %d\n", led_num);
printf("brightness is %d\n", brightness);
return 0;
diff --git a/include/hal/sunxi_hal_ledc.h b/include/hal/sunxi_hal_ledc.h
index a386338..e5a70d1 100644
--- a/include/hal/sunxi_hal_ledc.h
+++ b/include/hal/sunxi_hal_ledc.h
@@ -43,6 +43,7 @@
unsigned long long wait_time1_ns;
unsigned int wait_data_time_ns;
char *output_mode;
+ unsigned int *align_dma_buf;
unsigned int *data;
unsigned int length;
};
@@ -86,7 +87,7 @@
int hal_ledc_init(void);
void hal_ledc_deinit(void);
-void hal_ledc_trans_data(struct ledc_config *ledc);
+int hal_ledc_trans_data(struct ledc_config *ledc);
void hal_ledc_clear_all_irq(void);
unsigned int hal_ledc_get_irq_status(void);
void hal_ledc_dma_callback(void *para);
DMA下 LED 颜色异常
diff --git a/hal/source/ledc/hal_ledc.c b/hal/source/ledc/hal_ledc.c
index ddf471f4..8d818662 100755
--- a/hal/source/ledc/hal_ledc.c
+++ b/hal/source/ledc/hal_ledc.c
@@ -308,11 +308,15 @@ static void ledc_set_wait_data_time_ns(unsigned int wait_data_time_ns)
hal_writel(reg_val, base_addr + LEDC_DATA_FINISH_CNT_REG);
}
+/*
+ * set the num of leds on the led-strip
+ * max support up to 1024 leds
+ */
static void ledc_set_length(unsigned int length)
{
unsigned int reg_val;
- if (length == 0)
+ if (length == 0 || length > 1024)
return;
reg_val = hal_readl(base_addr + LEDC_CTRL_REG);
@@ -721,12 +725,22 @@ void hal_ledc_deinit(void)
}
}
-int sunxi_set_all_led(unsigned int brightness)
+/*
+ * set the brightness of all the leds in led-strip to a uniform value
+ * @length: the num of leds on led-strip
+ * @brightness: the brightness data
+ */
+int sunxi_set_all_led(unsigned int length, unsigned int brightness)
{
int i, ret;
- led->config.length = led->config.led_count;
- for(i = 0;i < led->config.led_count;i++)
+ if (length > led->config.led_count) {
+ led_err("%d: max support 1024 leds\n", length);
+ return -1;
+ }
+
+ led->config.length = length;
+ for(i = 0;i < led->length;i++)
led->config.data[i] = brightness;
ret = hal_ledc_trans_data(&led->config);
@@ -737,7 +751,13 @@ int sunxi_set_all_led(unsigned int brightness)
return 0;
}
-int sunxi_set_led_brightness(int led_num, unsigned int brightness)
+/*
+ * set the brightness of each led on the led strip
+ * @length: all the num of leds on the led strip
+ * @led_num: the specified led that you want to set
+ * @brightness: the led brightness data
+ */
+int sunxi_set_led_brightness(unsigned int length, unsigned int led_num, unsigned int brightness)
{
u32 reg_val;
int i, ret;
@@ -747,12 +767,13 @@ int sunxi_set_led_brightness(int led_num, unsigned int brightness)
return -1;
}
- if (led_num > led->config.led_count) {
+ if (length > led->config.led_count || len_num > length) {
led_err("has not the %d led\n", led_num);
return -1;
}
- led->config.length = led_num;
+ led->config.length = length;
+ /* set the specified led brightness, others set default brightness: 0x0*/
led->config.data[led_num-1] = brightness;
for (i = 0; i < led_num; i++)
@leomini5 我这边没有D1s的板卡，在T113上测试通过，测试1024颗灯，这个可能是RV才有的bug？
之前在其他帖发过DMA模式的patch，这里同步下
lichee/linux-5.4/drivers/leds/leds-sunxi.c
// SPDX-License-Identifier: GPL-2.0-only
/*
* drivers/leds/leds-sunxi.c - Allwinner RGB LED Driver
*
* Copyright (C) 2018 Allwinner Technology Limited. All rights reserved.
* http://www.allwinnertech.com
*
*Author : Albert Yu <yuxyun@allwinnertech.com>
* Lewis <liuyu@allwinnertech.com>
* This program is free software; you can redistribute it and/or modify
* it under the terms of the GNU General Public License version 2 as
* published by the Free Software Foundation.
*
*/
#include <linux/module.h>
#include <linux/delay.h>
#include <linux/leds.h>
#include <linux/io.h>
#include <linux/of.h>
#include <linux/slab.h>
#include <linux/clk.h>
#include <linux/dmaengine.h>
#include <linux/interrupt.h>
#include <linux/platform_device.h>
#include <linux/pinctrl/consumer.h>
#include <linux/dma-mapping.h>
#include <linux/debugfs.h>
#include <linux/uaccess.h>
#include <linux/delay.h>
#include <linux/regulator/consumer.h>
#include <linux/reset.h>
#if IS_ENABLED(CONFIG_PM)
#include <linux/pm.h>
#endif
#include "leds-sunxi.h"
/* For debug */
#define LED_ERR(fmt, arg...) pr_err("%s()%d - "fmt, __func__, __LINE__, ##arg)
#define dprintk(level_mask, fmt, arg...) \
do { \
if (unlikely(debug_mask & level_mask)) \
pr_warn("%s()%d - "fmt, __func__, __LINE__, ##arg); \
} while (0)
static u32 debug_mask = 1;
static struct sunxi_led *sunxi_led_global;
static struct class *led_class;
#define sunxi_slave_id(d, s) (((d)<<16) | (s))
/*For Driver */
static void led_dump_reg(struct sunxi_led *led, u32 offset, u32 len)
{
u32 i;
u8 buf[64], cnt = 0;
for (i = 0; i < len; i = i + REG_INTERVAL) {
if (i%HEXADECIMAL == 0)
cnt += sprintf(buf + cnt, "0x%08x: ",
(u32)(led->res->start + offset + i));
cnt += sprintf(buf + cnt, "%08x ",
readl(led->iomem_reg_base + offset + i));
if (i%HEXADECIMAL == REG_CL) {
pr_warn("%s\n", buf);
cnt = 0;
}
}
}
static void sunxi_clk_get(struct sunxi_led *led)
{
struct device *dev = led->dev;
struct device_node *np = dev->of_node;
led->clk_ledc = of_clk_get(np, 0);
if (IS_ERR(led->clk_ledc))
LED_ERR("failed to get clk_ledc!\n");
led->clk_cpuapb = of_clk_get(np, 1);
if (IS_ERR(led->clk_cpuapb))
LED_ERR("failed to get clk_cpuapb!\n");
}
static void sunxi_clk_put(struct sunxi_led *led)
{
clk_put(led->clk_ledc);
clk_put(led->clk_cpuapb);
led->clk_ledc = NULL;
led->clk_cpuapb = NULL;
}
static void sunxi_clk_enable(struct sunxi_led *led)
{
clk_prepare_enable(led->clk_ledc);
clk_prepare_enable(led->clk_cpuapb);
}
static void sunxi_clk_disable(struct sunxi_led *led)
{
clk_disable_unprepare(led->clk_ledc);
}
static void sunxi_clk_init(struct sunxi_led *led)
{
sunxi_clk_get(led);
sunxi_clk_enable(led);
}
static void sunxi_clk_deinit(struct sunxi_led *led)
{
sunxi_clk_disable(led);
sunxi_clk_put(led);
}
static u32 sunxi_get_reg(int offset)
{
struct sunxi_led *led = sunxi_led_global;
u32 value = ioread32(((u8 *)led->iomem_reg_base) + offset);
return value;
}
static void sunxi_set_reg(int offset, u32 value)
{
struct sunxi_led *led = sunxi_led_global;
iowrite32(value, ((u8 *)led->iomem_reg_base) + offset);
}
static inline void sunxi_set_reset_ns(struct sunxi_led *led)
{
u32 n, reg_val;
u32 mask = 0x1FFF;
u32 min = SUNXI_RESET_TIME_MIN_NS;
u32 max = SUNXI_RESET_TIME_MAX_NS;
if (led->reset_ns < min || led->reset_ns > max) {
LED_ERR("invalid parameter, reset_ns should be %u-%u!\n",
min, max);
return;
}
n = (led->reset_ns - 42) / 42;
reg_val = sunxi_get_reg(LED_RESET_TIMING_CTRL_REG_OFFSET);
reg_val &= ~(mask << 16);
reg_val |= (n << 16);
sunxi_set_reg(LED_RESET_TIMING_CTRL_REG_OFFSET, reg_val);
}
static inline void sunxi_set_t1h_ns(struct sunxi_led *led)
{
u32 n, reg_val;
u32 mask = 0x3F;
u32 shift = 21;
u32 min = SUNXI_T1H_MIN_NS;
u32 max = SUNXI_T1H_MAX_NS;
if (led->t1h_ns < min || led->t1h_ns > max) {
LED_ERR("invalid parameter, t1h_ns should be %u-%u!\n",
min, max);
return;
}
n = (led->t1h_ns - 42) / 42;
reg_val = sunxi_get_reg(LED_T01_TIMING_CTRL_REG_OFFSET);
reg_val &= ~(mask << shift);
reg_val |= n << shift;
sunxi_set_reg(LED_T01_TIMING_CTRL_REG_OFFSET, reg_val);
}
static inline void sunxi_set_t1l_ns(struct sunxi_led *led)
{
u32 n, reg_val;
u32 mask = 0x1F;
u32 shift = 16;
u32 min = SUNXI_T1L_MIN_NS;
u32 max = SUNXI_T1L_MAX_NS;
if (led->t1l_ns < min || led->t1l_ns > max) {
LED_ERR("invalid parameter, t1l_ns should be %u-%u!\n",
min, max);
return;
}
n = (led->t1l_ns - 42) / 42;
reg_val = sunxi_get_reg(LED_T01_TIMING_CTRL_REG_OFFSET);
reg_val &= ~(mask << shift);
reg_val |= n << shift;
sunxi_set_reg(LED_T01_TIMING_CTRL_REG_OFFSET, reg_val);
}
static inline void sunxi_set_t0h_ns(struct sunxi_led *led)
{
u32 n, reg_val;
u32 mask = 0x1F;
u32 shift = 6;
u32 min = SUNXI_T0H_MIN_NS;
u32 max = SUNXI_T0H_MAX_NS;
if (led->t0h_ns < min || led->t0h_ns > max) {
LED_ERR("invalid parameter, t0h_ns should be %u-%u!\n",
min, max);
return;
}
n = (led->t0h_ns - 42) / 42;
reg_val = sunxi_get_reg(LED_T01_TIMING_CTRL_REG_OFFSET);
reg_val &= ~(mask << shift);
reg_val |= n << shift;
sunxi_set_reg(LED_T01_TIMING_CTRL_REG_OFFSET, reg_val);
}
static inline void sunxi_set_t0l_ns(struct sunxi_led *led)
{
u32 n, reg_val;
u32 min = SUNXI_T0L_MIN_NS;
u32 max = SUNXI_T0L_MAX_NS;
if (led->t0l_ns < min || led->t0l_ns > max) {
LED_ERR("invalid parameter, t0l_ns should be %u-%u!\n",
min, max);
return;
}
n = (led->t0l_ns - 42) / 42;
reg_val = sunxi_get_reg(LED_T01_TIMING_CTRL_REG_OFFSET);
reg_val &= ~0x3F;
reg_val |= n;
sunxi_set_reg(LED_T01_TIMING_CTRL_REG_OFFSET, reg_val);
}
static inline void sunxi_set_wait_time0_ns(struct sunxi_led *led)
{
u32 n, reg_val;
u32 min = SUNXI_WAIT_TIME0_MIN_NS;
u32 max = SUNXI_WAIT_TIME0_MAX_NS;
if (led->wait_time0_ns < min || led->wait_time0_ns > max) {
LED_ERR("invalid parameter, wait_time0_ns should be %u-%u!\n",
min, max);
return;
}
n = (led->wait_time0_ns - 42) / 42;
reg_val = (1 << 8) | n;
sunxi_set_reg(LEDC_WAIT_TIME0_CTRL_REG, reg_val);
}
static inline void sunxi_set_wait_time1_ns(struct sunxi_led *led)
{
unsigned long long tmp, max = SUNXI_WAIT_TIME1_MAX_NS;
u32 min = SUNXI_WAIT_TIME1_MIN_NS;
u32 n, reg_val;
if (led->wait_time1_ns < min || led->wait_time1_ns > max) {
LED_ERR("invalid parameter, wait_time1_ns should be %u-%llu!\n",
min, max);
return;
}
tmp = led->wait_time1_ns;
n = div_u64(tmp, 42);
n -= 1;
reg_val = (1 << 31) | n;
sunxi_set_reg(LEDC_WAIT_TIME1_CTRL_REG, reg_val);
}
static inline void sunxi_set_wait_data_time_ns(struct sunxi_led *led)
{
u32 min, max;
#ifndef SUNXI_FPGA_LEDC
u32 mask = 0x1FFF, shift = 16, reg_val = 0, n;
#endif
min = SUNXI_WAIT_DATA_TIME_MIN_NS;
#ifdef SUNXI_FPGA_LEDC
/*
* For FPGA platforms, it is easy to meet wait data timeout for
* the obvious latency of task which is because of less cpu cores
* and lower cpu frequency compared with IC platforms, so here we
* permit long enough time latency.
*/
max = SUNXI_WAIT_DATA_TIME_MAX_NS_FPGA;
#else /* SUNXI_FPGA_LEDC */
max = SUNXI_WAIT_DATA_TIME_MAX_NS_IC;
#endif /* SUNXI_FPGA_LEDC */
if (led->wait_data_time_ns < min || led->wait_data_time_ns > max) {
LED_ERR("invalid parameter, wait_data_time_ns should be %u-%u!\n",
min, max);
return;
}
#ifndef SUNXI_FPGA_LEDC
n = (led->wait_data_time_ns - 42) / 42;
reg_val &= ~(mask << shift);
reg_val |= (n << shift);
sunxi_set_reg(LEDC_DATA_FINISH_CNT_REG_OFFSET, reg_val);
#endif /* SUNXI_FPGA_LEDC */
}
static void sunxi_ledc_set_time(struct sunxi_led *led)
{
sunxi_set_reset_ns(led);
sunxi_set_t1h_ns(led);
sunxi_set_t1l_ns(led);
sunxi_set_t0h_ns(led);
sunxi_set_t0l_ns(led);
sunxi_set_wait_time0_ns(led);
sunxi_set_wait_time1_ns(led);
sunxi_set_wait_data_time_ns(led);
}
static void sunxi_ledc_set_length(struct sunxi_led *led)
{
u32 reg_val;
u32 length = led->length;
if (length == 0)
return;
if (length > led->led_count)
return;
reg_val = sunxi_get_reg(LEDC_CTRL_REG_OFFSET);
reg_val &= ~(0x1FFF << 16);
reg_val |= length << 16;
sunxi_set_reg(LEDC_CTRL_REG_OFFSET, reg_val);
reg_val = sunxi_get_reg(LED_RESET_TIMING_CTRL_REG_OFFSET);
reg_val &= ~0x3FF;
reg_val |= length - 1;
sunxi_set_reg(LED_RESET_TIMING_CTRL_REG_OFFSET, reg_val);
}
static void sunxi_ledc_set_output_mode(struct sunxi_led *led, const char *str)
{
u32 val;
u32 mask = 0x7;
u32 shift = 6;
u32 reg_val = sunxi_get_reg(LEDC_CTRL_REG_OFFSET);
if (str != NULL) {
if (!strncmp(str, "GRB", 3))
val = SUNXI_OUTPUT_GRB;
else if (!strncmp(str, "GBR", 3))
val = SUNXI_OUTPUT_GBR;
else if (!strncmp(str, "RGB", 3))
val = SUNXI_OUTPUT_RGB;
else if (!strncmp(str, "RBG", 3))
val = SUNXI_OUTPUT_RBG;
else if (!strncmp(str, "BGR", 3))
val = SUNXI_OUTPUT_BGR;
else if (!strncmp(str, "BRG", 3))
val = SUNXI_OUTPUT_BRG;
else
return;
} else {
val = led->output_mode.val;
}
reg_val &= ~(mask << shift);
reg_val |= val;
sunxi_set_reg(LEDC_CTRL_REG_OFFSET, reg_val);
if (str != NULL) {
if (strncmp(str, led->output_mode.str, 3))
memcpy(led->output_mode.str, str, 3);
}
if (val != led->output_mode.val)
led->output_mode.val = val;
}
static void sunxi_ledc_enable_irq(u32 mask)
{
u32 reg_val = 0;
reg_val |= mask;
sunxi_set_reg(LEDC_INT_CTRL_REG_OFFSET, reg_val);
}
static void sunxi_ledc_disable_irq(u32 mask)
{
u32 reg_val = 0;
reg_val = sunxi_get_reg(LEDC_INT_CTRL_REG_OFFSET);
reg_val &= ~mask;
sunxi_set_reg(LEDC_INT_CTRL_REG_OFFSET, reg_val);
}
static inline void sunxi_ledc_enable(struct sunxi_led *led)
{
u32 reg_val;
reg_val = sunxi_get_reg(LEDC_CTRL_REG_OFFSET);
reg_val |= 1;
sunxi_set_reg(LEDC_CTRL_REG_OFFSET, reg_val);
}
static inline void sunxi_ledc_reset(struct sunxi_led *led)
{
u32 reg_val = sunxi_get_reg(LEDC_CTRL_REG_OFFSET);
sunxi_ledc_disable_irq(LEDC_TRANS_FINISH_INT_EN | LEDC_FIFO_CPUREQ_INT_EN
| LEDC_WAITDATA_TIMEOUT_INT_EN | LEDC_FIFO_OVERFLOW_INT_EN
| LEDC_GLOBAL_INT_EN);
if (debug_mask & DEBUG_INFO2) {
dprintk(DEBUG_INFO2, "dump reg:\n");
led_dump_reg(led, 0, 0x30);
}
reg_val |= 1 << 1;
sunxi_set_reg(LEDC_CTRL_REG_OFFSET, reg_val);
}
#ifdef CONFIG_DEBUG_FS
static ssize_t reset_ns_write(struct file *filp, const char __user *buf,
size_t count, loff_t *offp)
{
int err;
char buffer[64];
u32 min, max;
unsigned long val;
struct sunxi_led *led = sunxi_led_global;
min = SUNXI_RESET_TIME_MIN_NS;
max = SUNXI_RESET_TIME_MAX_NS;
if (count >= sizeof(buffer))
goto err_out;
if (copy_from_user(buffer, buf, count))
goto err_out;
buffer[count] = '\0';
err = kstrtoul(buffer, 10, &val);
if (err)
goto err_out;
if (val < min || val > max)
goto err_out;
led->reset_ns = val;
sunxi_set_reset_ns(led);
*offp += count;
return count;
err_out:
LED_ERR("invalid parameter, reset_ns should be %u-%u!\n",
min, max);
return -EINVAL;
}
static ssize_t reset_ns_read(struct file *filp, char __user *buf,
size_t count, loff_t *offp)
{
int r;
char buffer[64];
struct sunxi_led *led = sunxi_led_global;
r = snprintf(buffer, 64, "%u\n", led->reset_ns);
return simple_read_from_buffer(buf, count, offp, buffer, r);
}
static const struct file_operations reset_ns_fops = {
.owner = THIS_MODULE,
.write = reset_ns_write,
.read = reset_ns_read,
};
static ssize_t t1h_ns_write(struct file *filp, const char __user *buf,
size_t count, loff_t *offp)
{
int err;
char buffer[64];
u32 min, max;
unsigned long val;
struct sunxi_led *led = sunxi_led_global;
min = SUNXI_T1H_MIN_NS;
max = SUNXI_T1H_MAX_NS;
if (count >= sizeof(buffer))
return -EINVAL;
if (copy_from_user(buffer, buf, count))
return -EFAULT;
buffer[count] = '\0';
err = kstrtoul(buffer, 10, &val);
if (err)
return -EINVAL;
if (val < min || val > max)
goto err_out;
led->t1h_ns = val;
sunxi_set_t1h_ns(led);
*offp += count;
return count;
err_out:
LED_ERR("invalid parameter, t1h_ns should be %u-%u!\n",
min, max);
return -EINVAL;
}
static ssize_t t1h_ns_read(struct file *filp, char __user *buf,
size_t count, loff_t *offp)
{
int r;
char buffer[64];
struct sunxi_led *led = sunxi_led_global;
r = snprintf(buffer, 64, "%u\n", led->t1h_ns);
return simple_read_from_buffer(buf, count, offp, buffer, r);
}
static const struct file_operations t1h_ns_fops = {
.owner = THIS_MODULE,
.write = t1h_ns_write,
.read = t1h_ns_read,
};
static ssize_t t1l_ns_write(struct file *filp, const char __user *buf,
size_t count, loff_t *offp)
{
int err;
char buffer[64];
u32 min, max;
unsigned long val;
struct sunxi_led *led = sunxi_led_global;
min = SUNXI_T1L_MIN_NS;
max = SUNXI_T1L_MAX_NS;
if (count >= sizeof(buffer))
goto err_out;
if (copy_from_user(buffer, buf, count))
goto err_out;
buffer[count] = '\0';
err = kstrtoul(buffer, 10, &val);
if (err)
goto err_out;
if (val < min || val > max)
goto err_out;
led->t1l_ns = val;
sunxi_set_t1l_ns(led);
*offp += count;
return count;
err_out:
LED_ERR("invalid parameter, t1l_ns should be %u-%u!\n",
min, max);
return -EINVAL;
}
static ssize_t t1l_ns_read(struct file *filp, char __user *buf,
size_t count, loff_t *offp)
{
int r;
char buffer[64];
struct sunxi_led *led = sunxi_led_global;
r = snprintf(buffer, 64, "%u\n", led->t1l_ns);
return simple_read_from_buffer(buf, count, offp, buffer, r);
}
static const struct file_operations t1l_ns_fops = {
.owner = THIS_MODULE,
.write = t1l_ns_write,
.read = t1l_ns_read,
};
static ssize_t t0h_ns_write(struct file *filp, const char __user *buf,
size_t count, loff_t *offp)
{
int err;
char buffer[64];
u32 min, max;
unsigned long val;
struct sunxi_led *led = sunxi_led_global;
min = SUNXI_T0H_MIN_NS;
max = SUNXI_T0H_MAX_NS;
if (count >= sizeof(buffer))
goto err_out;
if (copy_from_user(buffer, buf, count))
goto err_out;
buffer[count] = '\0';
err = kstrtoul(buffer, 10, &val);
if (err)
goto err_out;
if (val < min || val > max)
goto err_out;
led->t0h_ns = val;
sunxi_set_t0h_ns(led);
*offp += count;
return count;
err_out:
LED_ERR("invalid parameter, t0h_ns should be %u-%u!\n",
min, max);
return -EINVAL;
}
static ssize_t t0h_ns_read(struct file *filp, char __user *buf,
size_t count, loff_t *offp)
{
int r;
char buffer[64];
struct sunxi_led *led = sunxi_led_global;
r = snprintf(buffer, 64, "%u\n", led->t0h_ns);
return simple_read_from_buffer(buf, count, offp, buffer, r);
}
static const struct file_operations t0h_ns_fops = {
.owner = THIS_MODULE,
.write = t0h_ns_write,
.read = t0h_ns_read,
};
static ssize_t t0l_ns_write(struct file *filp, const char __user *buf,
size_t count, loff_t *offp)
{
int err;
char buffer[64];
u32 min, max;
unsigned long val;
struct sunxi_led *led = sunxi_led_global;
min = SUNXI_T0L_MIN_NS;
max = SUNXI_T0L_MAX_NS;
if (count >= sizeof(buffer))
goto err_out;
if (copy_from_user(buffer, buf, count))
goto err_out;
buffer[count] = '\0';
err = kstrtoul(buffer, 10, &val);
if (err)
goto err_out;
if (val < min || val > max)
goto err_out;
led->t0l_ns = val;
sunxi_set_t0l_ns(led);
*offp += count;
return count;
err_out:
LED_ERR("invalid parameter, t0l_ns should be %u-%u!\n",
min, max);
return -EINVAL;
}
static ssize_t t0l_ns_read(struct file *filp, char __user *buf,
size_t count, loff_t *offp)
{
int r;
char buffer[64];
struct sunxi_led *led = sunxi_led_global;
r = snprintf(buffer, 64, "%u\n", led->t0l_ns);
return simple_read_from_buffer(buf, count, offp, buffer, r);
}
static const struct file_operations t0l_ns_fops = {
.owner = THIS_MODULE,
.write = t0l_ns_write,
.read = t0l_ns_read,
};
static ssize_t wait_time0_ns_write(struct file *filp, const char __user *buf,
size_t count, loff_t *offp)
{
int err;
char buffer[64];
u32 min, max;
unsigned long val;
struct sunxi_led *led = sunxi_led_global;
min = SUNXI_WAIT_TIME0_MIN_NS;
max = SUNXI_WAIT_TIME0_MAX_NS;
if (count >= sizeof(buffer))
goto err_out;
if (copy_from_user(buffer, buf, count))
goto err_out;
buffer[count] = '\0';
err = kstrtoul(buffer, 10, &val);
if (err)
goto err_out;
if (val < min || val > max)
goto err_out;
led->wait_time0_ns = val;
sunxi_set_wait_time0_ns(led);
*offp += count;
return count;
err_out:
LED_ERR("invalid parameter, wait_time0_ns should be %u-%u!\n",
min, max);
return -EINVAL;
}
static ssize_t wait_time0_ns_read(struct file *filp, char __user *buf,
size_t count, loff_t *offp)
{
int r;
char buffer[64];
struct sunxi_led *led = sunxi_led_global;
r = snprintf(buffer, 64, "%u\n", led->wait_time0_ns);
return simple_read_from_buffer(buf, count, offp, buffer, r);
}
static const struct file_operations wait_time0_ns_fops = {
.owner = THIS_MODULE,
.write = wait_time0_ns_write,
.read = wait_time0_ns_read,
};
static ssize_t wait_time1_ns_write(struct file *filp, const char __user *buf,
size_t count, loff_t *offp)
{
int err;
char buffer[64];
u32 min;
unsigned long long max;
unsigned long long val;
struct sunxi_led *led = sunxi_led_global;
min = SUNXI_WAIT_TIME1_MIN_NS;
max = SUNXI_WAIT_TIME1_MAX_NS;
if (count >= sizeof(buffer))
goto err_out;
if (copy_from_user(buffer, buf, count))
goto err_out;
buffer[count] = '\0';
err = kstrtoull(buffer, 10, &val);
if (err)
goto err_out;
if (val < min || val > max)
goto err_out;
led->wait_time1_ns = val;
sunxi_set_wait_time1_ns(led);
*offp += count;
return count;
err_out:
LED_ERR("invalid parameter, wait_time1_ns should be %u-%lld!\n",
min, max);
return -EINVAL;
}
static ssize_t wait_time1_ns_read(struct file *filp, char __user *buf,
size_t count, loff_t *offp)
{
int r;
char buffer[64];
struct sunxi_led *led = sunxi_led_global;
r = snprintf(buffer, 64, "%lld\n", led->wait_time1_ns);
return simple_read_from_buffer(buf, count, offp, buffer, r);
}
static const struct file_operations wait_time1_ns_fops = {
.owner = THIS_MODULE,
.write = wait_time1_ns_write,
.read = wait_time1_ns_read,
};
static ssize_t wait_data_time_ns_write(struct file *filp,
const char __user *buf,
size_t count, loff_t *offp)
{
int err;
char buffer[64];
u32 min, max;
unsigned long val;
struct sunxi_led *led = sunxi_led_global;
min = SUNXI_WAIT_DATA_TIME_MIN_NS;
#ifdef SUNXI_FPGA_LEDC
max = SUNXI_WAIT_DATA_TIME_MAX_NS_FPGA;
#else
max = SUNXI_WAIT_DATA_TIME_MAX_NS_IC;
#endif
if (count >= sizeof(buffer))
goto err_out;
if (copy_from_user(buffer, buf, count))
goto err_out;
buffer[count] = '\0';
err = kstrtoul(buffer, 10, &val);
if (err)
goto err_out;
if (val < min || val > max)
goto err_out;
led->wait_data_time_ns = val;
sunxi_set_wait_data_time_ns(led);
*offp += count;
return count;
err_out:
LED_ERR("invalid parameter, wait_data_time_ns should be %u-%u!\n",
min, max);
return -EINVAL;
}
static ssize_t wait_data_time_ns_read(struct file *filp, char __user *buf,
size_t count, loff_t *offp)
{
int r;
char buffer[64];
struct sunxi_led *led = sunxi_led_global;
r = snprintf(buffer, 64, "%u\n", led->wait_data_time_ns);
return simple_read_from_buffer(buf, count, offp, buffer, r);
}
static const struct file_operations wait_data_time_ns_fops = {
.owner = THIS_MODULE,
.write = wait_data_time_ns_write,
.read = wait_data_time_ns_read,
};
static int data_show(struct seq_file *s, void *data)
{
int i;
struct sunxi_led *led = sunxi_led_global;
for (i = 0; i < led->led_count; i++) {
if (!(i % 4)) {
if (i + 4 <= led->led_count)
seq_printf(s, "%04d-%04d", i, i + 4);
else
seq_printf(s, "%04d-%04d", i, led->led_count);
}
seq_printf(s, " 0x%08x", led->data[i]);
if (((i % 4) == 3) || (i == led->led_count - 1))
seq_puts(s, "\n");
}
return 0;
}
static int data_open(struct inode *inode, struct file *file)
{
return single_open(file, data_show, inode->i_private);
}
static const struct file_operations data_fops = {
.owner = THIS_MODULE,
.open = data_open,
.read = seq_read,
.llseek = seq_lseek,
.release = single_release,
};
static ssize_t output_mode_write(struct file *filp, const char __user *buf,
size_t count, loff_t *offp)
{
char buffer[64];
struct sunxi_led *led = sunxi_led_global;
if (count >= sizeof(buffer))
goto err_out;
if (copy_from_user(buffer, buf, count))
goto err_out;
buffer[count] = '\0';
sunxi_ledc_set_output_mode(led, buffer);
*offp += count;
return count;
err_out:
LED_ERR("invalid parameter!\n");
return -EINVAL;
}
static ssize_t output_mode_read(struct file *filp, char __user *buf,
size_t count, loff_t *offp)
{
int r;
char buffer[64];
struct sunxi_led *led = sunxi_led_global;
r = snprintf(buffer, 64, "%s\n", led->output_mode.str);
return simple_read_from_buffer(buf, count, offp, buffer, r);
}
static const struct file_operations output_mode_fops = {
.owner = THIS_MODULE,
.write = output_mode_write,
.read = output_mode_read,
};
static ssize_t hwversion_read(struct file *filp, char __user *buf,
size_t count, loff_t *offp)
{
int r;
char buffer[64];
u32 reg_val, major_ver, minor_ver;
reg_val = sunxi_get_reg(LEDC_VER_NUM_REG);
major_ver = reg_val >> 16;
minor_ver = reg_val & 0xF;
r = snprintf(buffer, 64, "r%up%u\n", major_ver, minor_ver);
return simple_read_from_buffer(buf, count, offp, buffer, r);
}
static const struct file_operations hwversion_fops = {
.owner = THIS_MODULE,
.read = hwversion_read,
};
static void sunxi_led_create_debugfs(struct sunxi_led *led)
{
struct dentry *debugfs_dir, *debugfs_file;
debugfs_dir = debugfs_create_dir("sunxi_leds", NULL);
if (IS_ERR_OR_NULL(debugfs_dir)) {
LED_ERR("debugfs_create_dir failed!\n");
return;
}
led->debugfs_dir = debugfs_dir;
debugfs_file = debugfs_create_file("reset_ns", 0660,
debugfs_dir, NULL, &reset_ns_fops);
if (!debugfs_file)
LED_ERR("debugfs_create_file for reset_ns failed!\n");
debugfs_file = debugfs_create_file("t1h_ns", 0660,
debugfs_dir, NULL, &t1h_ns_fops);
if (!debugfs_file)
LED_ERR("debugfs_create_file for t1h_ns failed!\n");
debugfs_file = debugfs_create_file("t1l_ns", 0660,
debugfs_dir, NULL, &t1l_ns_fops);
if (!debugfs_file)
LED_ERR("debugfs_create_file for t1l_ns failed!\n");
debugfs_file = debugfs_create_file("t0h_ns", 0660,
debugfs_dir, NULL, &t0h_ns_fops);
if (!debugfs_file)
LED_ERR("debugfs_create_file for t0h_ns failed!\n");
debugfs_file = debugfs_create_file("t0l_ns", 0660,
debugfs_dir, NULL, &t0l_ns_fops);
if (!debugfs_file)
LED_ERR("debugfs_create_file for t0l_ns failed!\n");
debugfs_file = debugfs_create_file("wait_time0_ns", 0660,
debugfs_dir, NULL, &wait_time0_ns_fops);
if (!debugfs_file)
LED_ERR("debugfs_create_file for wait_time0_ns failed!\n");
debugfs_file = debugfs_create_file("wait_time1_ns", 0660,
debugfs_dir, NULL, &wait_time1_ns_fops);
if (!debugfs_file)
LED_ERR("debugfs_create_file for wait_time1_ns failed!\n");
debugfs_file = debugfs_create_file("wait_data_time_ns", 0660,
debugfs_dir, NULL, &wait_data_time_ns_fops);
if (!debugfs_file)
LED_ERR("debugfs_create_file for wait_data_time_ns failed!\n");
debugfs_file = debugfs_create_file("data", 0440,
debugfs_dir, NULL, &data_fops);
if (!debugfs_file)
LED_ERR("debugfs_create_file for data failed!\n");
debugfs_file = debugfs_create_file("output_mode", 0660,
debugfs_dir, NULL, &output_mode_fops);
if (!debugfs_file)
LED_ERR("debugfs_create_file for output_mode failed!\n");
if (!debugfs_file)
LED_ERR("debugfs_create_file for trans_mode failed!\n");
debugfs_file = debugfs_create_file("hwversion", 0440,
debugfs_dir, NULL, &hwversion_fops);
if (!debugfs_file)
LED_ERR("debugfs_create_file for hwversion failed!\n");
}
static void sunxi_led_remove_debugfs(struct sunxi_led *led)
{
debugfs_remove_recursive(led->debugfs_dir);
}
#endif /* CONFIG_DEBUG_FS */
static void sunxi_ledc_set_dma_mode(struct sunxi_led *led)
{
u32 reg_val = 0;
reg_val |= 1 << 5;
sunxi_set_reg(LEDC_DMA_CTRL_REG, reg_val);
sunxi_ledc_disable_irq(LEDC_FIFO_CPUREQ_INT_EN);
}
static void sunxi_ledc_set_cpu_mode(struct sunxi_led *led)
{
u32 reg_val = 0;
reg_val &= ~(1 << 5);
sunxi_set_reg(LEDC_DMA_CTRL_REG, reg_val);
sunxi_ledc_enable_irq(LEDC_FIFO_CPUREQ_INT_EN);
}
static void sunxi_ledc_dma_callback(void *param)
{
dprintk(DEBUG_INFO, "finish\n");
}
static void sunxi_ledc_trans_data(struct sunxi_led *led)
{
int i, err;
size_t size;
unsigned long flags;
phys_addr_t dst_addr;
struct dma_slave_config slave_config;
struct device *dev = led->dev;
struct dma_async_tx_descriptor *dma_desc;
/* less than 32 lights use cpu transmission. */
/* more than 32 lights use dma transmission. */
if (led->length <= SUNXI_LEDC_FIFO_DEPTH) {
dprintk(DEBUG_INFO, "cpu xfer\n");
ktime_get_coarse_real_ts64(&(led->start_time));
sunxi_ledc_set_time(led);
sunxi_ledc_set_output_mode(led, led->output_mode.str);
sunxi_ledc_set_cpu_mode(led);
sunxi_ledc_set_length(led);
sunxi_ledc_enable_irq(LEDC_TRANS_FINISH_INT_EN | LEDC_WAITDATA_TIMEOUT_INT_EN
| LEDC_FIFO_OVERFLOW_INT_EN | LEDC_GLOBAL_INT_EN);
sunxi_ledc_enable(led);
for (i = 0; i < led->length; i++)
sunxi_set_reg(LEDC_DATA_REG_OFFSET, led->data[i]);
} else {
dprintk(DEBUG_INFO, "dma xfer\n");
size = led->length * 4;
led->src_dma = dma_map_single(dev, led->data,
size, DMA_TO_DEVICE);
dst_addr = led->res->start + LEDC_DATA_REG_OFFSET;
flags = DMA_PREP_INTERRUPT | DMA_CTRL_ACK;
slave_config.direction = DMA_MEM_TO_DEV;
slave_config.src_addr = led->src_dma;
slave_config.dst_addr = dst_addr;
slave_config.src_addr_width = DMA_SLAVE_BUSWIDTH_4_BYTES;
slave_config.dst_addr_width = DMA_SLAVE_BUSWIDTH_4_BYTES;
slave_config.src_maxburst = 4;
slave_config.dst_maxburst = 4;
err = dmaengine_slave_config(led->dma_chan, &slave_config);
if (err < 0) {
LED_ERR("dmaengine_slave_config failed!\n");
return;
}
dma_desc = dmaengine_prep_slave_single(led->dma_chan,
led->src_dma,
size,
DMA_MEM_TO_DEV,
flags);
if (!dma_desc) {
LED_ERR("dmaengine_prep_slave_single failed!\n");
return;
}
dma_desc->callback = sunxi_ledc_dma_callback;
dmaengine_submit(dma_desc);
dma_async_issue_pending(led->dma_chan);
ktime_get_coarse_real_ts64(&(led->start_time));
sunxi_ledc_set_time(led);
sunxi_ledc_set_output_mode(led, led->output_mode.str);
sunxi_ledc_set_dma_mode(led);
sunxi_ledc_set_length(led);
sunxi_ledc_enable_irq(LEDC_TRANS_FINISH_INT_EN | LEDC_WAITDATA_TIMEOUT_INT_EN
| LEDC_FIFO_OVERFLOW_INT_EN | LEDC_GLOBAL_INT_EN);
sunxi_ledc_enable(led);
}
}
static inline void sunxi_ledc_clear_all_irq(void)
{
u32 reg_val = sunxi_get_reg(LEDC_INT_STS_REG_OFFSET);
reg_val &= ~0x1F;
sunxi_set_reg(LEDC_INT_STS_REG_OFFSET, reg_val);
}
static inline void sunxi_ledc_clear_irq(enum sunxi_ledc_irq_status_reg irq)
{
u32 reg_val = sunxi_get_reg(LEDC_INT_STS_REG_OFFSET);
reg_val &= ~irq;
sunxi_set_reg(LEDC_INT_STS_REG_OFFSET, reg_val);
}
static int sunxi_ledc_complete(struct sunxi_led *led)
{
unsigned long flags = 0;
unsigned long timeout = 0;
u32 reg_val;
/*wait_event_timeout return 0 : timeout
*wait_event_timeout return > 0 : thr left time
* */
timeout = wait_event_timeout(led->wait, led->result, 5*HZ);
if (timeout == 0) {
reg_val = sunxi_get_reg(LEDC_INT_STS_REG_OFFSET);
pr_err("LEDC INTERRUPT STATUS REG IS %x", reg_val);
LED_ERR("led xfer timeout\n");
reg_val = sunxi_get_reg(LEDC_INT_STS_REG_OFFSET);
pr_err("LEDC INTERRUPT STATUS REG IS %x", reg_val);
return -ETIME;
} else if (led->result == RESULT_ERR) {
return -ECOMM;
}
dprintk(DEBUG_INFO, "xfer complete\n");
spin_lock_irqsave(&led->lock, flags);
led->result = 0;
spin_unlock_irqrestore(&led->lock, flags);
return 0;
}
static irqreturn_t sunxi_ledc_irq_handler(int irq, void *dev_id)
{
long delta_time_ns;
u32 irq_status, max_ns;
struct sunxi_led *led = sunxi_led_global;
struct device *dev = led->dev;
struct timespec64 current_time;
spin_lock(&led->lock);
irq_status = sunxi_get_reg(LEDC_INT_STS_REG_OFFSET);
sunxi_ledc_clear_all_irq();
if (irq_status & LEDC_TRANS_FINISH_INT) {
sunxi_ledc_reset(led);
led->result = RESULT_COMPLETE;
goto out;
}
if (irq_status & LEDC_WAITDATA_TIMEOUT_INT) {
ktime_get_coarse_real_ts64(¤t_time);
delta_time_ns = current_time.tv_sec - led->start_time.tv_sec;
delta_time_ns *= 1000 * 1000 * 1000;
delta_time_ns += current_time.tv_nsec - led->start_time.tv_nsec;
max_ns = led->wait_data_time_ns;
if (delta_time_ns <= max_ns) {
spin_unlock(&led->lock);
return IRQ_HANDLED;
}
sunxi_ledc_reset(led);
if (delta_time_ns <= max_ns * 2) {
sunxi_ledc_trans_data(led);
} else {
LED_ERR("wait time is more than %d ns,"
"going to reset ledc and drop this operation!\n",
max_ns);
led->result = RESULT_ERR;
}
goto out;
}
if (irq_status & LEDC_FIFO_OVERFLOW_INT) {
LED_ERR("there exists fifo overflow issue, irq_status=0x%x!\n",
irq_status);
sunxi_ledc_reset(led);
led->result = RESULT_ERR;
goto out;
}
out:
if (led->dma_chan)
dma_unmap_single(dev, led->src_dma, led->length * 4, DMA_TO_DEVICE);
wake_up(&led->wait);
led->length = 0;
spin_unlock(&led->lock);
return IRQ_HANDLED;
}
static int sunxi_ledc_irq_init(struct sunxi_led *led)
{
int err;
struct device *dev = led->dev;
unsigned long flags = 0;
const char *name = "ledcirq";
struct platform_device *pdev;
pdev = container_of(dev, struct platform_device, dev);
spin_lock_init(&led->lock);
led->irqnum = platform_get_irq(pdev, 0);
if (led->irqnum < 0)
LED_ERR("failed to get ledc irq!\n");
err = request_irq(led->irqnum, sunxi_ledc_irq_handler,
flags, name, dev);
if (err) {
LED_ERR("failed to install IRQ handler for irqnum %d\n",
led->irqnum);
return -EPERM;
}
return 0;
}
static void sunxi_ledc_irq_deinit(struct sunxi_led *led)
{
free_irq(led->irqnum, led->dev);
sunxi_ledc_disable_irq(LEDC_TRANS_FINISH_INT_EN | LEDC_FIFO_CPUREQ_INT_EN
| LEDC_WAITDATA_TIMEOUT_INT_EN | LEDC_FIFO_OVERFLOW_INT_EN
| LEDC_GLOBAL_INT_EN);
}
static void sunxi_ledc_pinctrl_init(struct sunxi_led *led)
{
struct device *dev = led->dev;
struct pinctrl *pinctrl = devm_pinctrl_get_select_default(dev);
led->pctrl = pinctrl;
if (IS_ERR(pinctrl))
LED_ERR("devm_pinctrl_get_select_default failed!\n");
}
static int led_regulator_request(struct sunxi_led *led)
{
struct regulator *regu = NULL;
/* Consider "n*" as nocare. Support "none", "nocare", "null", "" etc. */
if ((led->regulator_id[0] == 'n') || (led->regulator_id[0] == 0))
return 0;
regu = regulator_get(NULL, led->regulator_id);
if (IS_ERR(regu)) {
LED_ERR("get regulator %s failed!\n", led->regulator_id);
return -1;
}
led->regulator = regu;
return 0;
}
static int led_regulator_release(struct sunxi_led *led)
{
if (led->regulator == NULL)
return 0;
regulator_put(led->regulator);
led->regulator = NULL;
return 1;
}
static int sunxi_ledc_dma_get(struct sunxi_led *led)
{
if (led->dma_chan == NULL) {
led->dma_chan = dma_request_chan(led->dev, "tx");
if (IS_ERR(led->dma_chan)) {
LED_ERR("failed to get the DMA channel!\n");
return -EFAULT;
}
}
return 0;
}
static int sunxi_set_led_brightness(struct led_classdev *led_cdev,
enum led_brightness value)
{
unsigned long flags;
u32 r, g, b, shift, old_data, new_data, length;
struct sunxi_led_info *pinfo;
struct sunxi_led_classdev_group *pcdev_group;
struct sunxi_led *led = sunxi_led_global;
int err;
pinfo = container_of(led_cdev, struct sunxi_led_info, cdev);
switch (pinfo->type) {
case LED_TYPE_G:
pcdev_group = container_of(pinfo,
struct sunxi_led_classdev_group, g);
g = value;
shift = 16;
break;
case LED_TYPE_R:
pcdev_group = container_of(pinfo,
struct sunxi_led_classdev_group, r);
r = value;
shift = 8;
break;
case LED_TYPE_B:
pcdev_group = container_of(pinfo,
struct sunxi_led_classdev_group, b);
b = value;
shift = 0;
break;
}
old_data = led->data[pcdev_group->led_num];
if (((old_data >> shift) & 0xFF) == value)
return 0;
if (pinfo->type != LED_TYPE_R)
r = pcdev_group->r.cdev.brightness;
if (pinfo->type != LED_TYPE_G)
g = pcdev_group->g.cdev.brightness;
if (pinfo->type != LED_TYPE_B)
b = pcdev_group->b.cdev.brightness;
/* LEDC treats input data as GRB by default */
new_data = (g << 16) | (r << 8) | b;
length = pcdev_group->led_num + 1;
spin_lock_irqsave(&led->lock, flags);
led->data[pcdev_group->led_num] = new_data;
led->length = length;
spin_unlock_irqrestore(&led->lock, flags);
/* prepare for dma xfer, dynamic apply dma channel */
if (led->length > SUNXI_LEDC_FIFO_DEPTH) {
err = sunxi_ledc_dma_get(led);
if (err)
return err;
}
sunxi_ledc_trans_data(led);
if (debug_mask & DEBUG_INFO2) {
dprintk(DEBUG_INFO2, "dump reg:\n");
led_dump_reg(led, 0, 0x30);
}
sunxi_ledc_complete(led);
if (debug_mask & DEBUG_INFO1)
pr_warn("num = %03u\n", length);
return 0;
}
static int sunxi_register_led_classdev(struct sunxi_led *led)
{
int i, err;
size_t size;
struct device *dev = led->dev;
struct led_classdev *pcdev_RGB;
dprintk(DEBUG_INIT, "led_classdev start\n");
if (!led->led_count)
led->led_count = SUNXI_DEFAULT_LED_COUNT;
size = sizeof(struct sunxi_led_classdev_group) * led->led_count;
led->pcdev_group = devm_kzalloc(dev, size, GFP_KERNEL);
if (!led->pcdev_group)
return -ENOMEM;
for (i = 0; i < led->led_count; i++) {
led->pcdev_group[i].r.type = LED_TYPE_R;
pcdev_RGB = &led->pcdev_group[i].r.cdev;
pcdev_RGB->name = devm_kzalloc(dev, 16, GFP_KERNEL);
if (!pcdev_RGB->name)
return -ENOMEM;
sprintf((char *)pcdev_RGB->name, "sunxi_led%dr", i);
pcdev_RGB->brightness = LED_OFF;
pcdev_RGB->brightness_set_blocking = sunxi_set_led_brightness;
pcdev_RGB->dev = dev;
err = led_classdev_register(dev, pcdev_RGB);
if (err < 0) {
LED_ERR("led_classdev_register %s failed!\n",
pcdev_RGB->name);
return err;
}
led->pcdev_group[i].g.type = LED_TYPE_G;
pcdev_RGB = &led->pcdev_group[i].g.cdev;
pcdev_RGB->name = devm_kzalloc(dev, 16, GFP_KERNEL);
if (!pcdev_RGB->name)
return -ENOMEM;
sprintf((char *)pcdev_RGB->name, "sunxi_led%dg", i);
pcdev_RGB->brightness = LED_OFF;
pcdev_RGB->brightness_set_blocking = sunxi_set_led_brightness;
pcdev_RGB->dev = dev;
err = led_classdev_register(dev, pcdev_RGB);
if (err < 0) {
LED_ERR("led_classdev_register %s failed!\n",
pcdev_RGB->name);
return err;
}
led->pcdev_group[i].b.type = LED_TYPE_B;
pcdev_RGB = &led->pcdev_group[i].b.cdev;
pcdev_RGB->name = devm_kzalloc(dev, 16, GFP_KERNEL);
if (!pcdev_RGB->name)
return -ENOMEM;
sprintf((char *)pcdev_RGB->name, "sunxi_led%db", i);
pcdev_RGB->brightness = LED_OFF;
pcdev_RGB->brightness_set_blocking = sunxi_set_led_brightness;
pcdev_RGB->dev = dev;
err = led_classdev_register(dev, pcdev_RGB);
if (err < 0) {
LED_ERR("led_classdev_register %s failed!\n",
pcdev_RGB->name);
return err;
}
led->pcdev_group[i].led_num = i;
}
size = sizeof(u32) * led->led_count;
led->data = devm_kzalloc(dev, size, GFP_KERNEL);
if (!led->data)
return -ENOMEM;
return 0;
}
static void sunxi_unregister_led_classdev(struct sunxi_led *led)
{
int i;
for (i = 0; i < led->led_count; i++) {
kfree(led->pcdev_group[i].b.cdev.name);
led->pcdev_group[i].b.cdev.name = NULL;
kfree(led->pcdev_group[i].g.cdev.name);
led->pcdev_group[i].g.cdev.name = NULL;
kfree(led->pcdev_group[i].r.cdev.name);
led->pcdev_group[i].r.cdev.name = NULL;
led_classdev_unregister(&led->pcdev_group[i].b.cdev);
led_classdev_unregister(&led->pcdev_group[i].g.cdev);
led_classdev_unregister(&led->pcdev_group[i].r.cdev);
}
kfree(led->data);
led->data = NULL;
kfree(led->pcdev_group);
led->pcdev_group = NULL;
}
static inline int sunxi_get_u32_of_property(const char *propname, int *val)
{
int err;
struct sunxi_led *led = sunxi_led_global;
struct device *dev = led->dev;
struct device_node *np = dev->of_node;
err = of_property_read_u32(np, propname, val);
if (err < 0)
LED_ERR("failed to get the value of propname %s!\n", propname);
return err;
}
static inline int sunxi_get_str_of_property(const char *propname,
const char **out_string)
{
int err;
struct sunxi_led *led = sunxi_led_global;
struct device *dev = led->dev;
struct device_node *np = dev->of_node;
err = of_property_read_string(np, propname, out_string);
if (err < 0)
LED_ERR("failed to get the string of propname %s!\n", propname);
return err;
}
static void sunxi_get_para_of_property(struct sunxi_led *led)
{
int err;
u32 val;
const char *str;
err = sunxi_get_u32_of_property("led_count", &val);
if (!err)
led->led_count = val;
memcpy(led->output_mode.str, "GRB", 3);
led->output_mode.val = SUNXI_OUTPUT_GRB;
err = sunxi_get_str_of_property("output_mode", &str);
if (!err)
if (!strncmp(str, "BRG", 3) ||
!strncmp(str, "GBR", 3) ||
!strncmp(str, "RGB", 3) ||
!strncmp(str, "RBG", 3) ||
!strncmp(str, "BGR", 3))
memcpy(led->output_mode.str, str, 3);
err = sunxi_get_str_of_property("led_regulator", &str);
if (!err) {
if (strlen(str) >= sizeof(led->regulator_id))
LED_ERR("illegal regulator id\n");
else {
strcpy(led->regulator_id, str);
pr_info("led_regulator: %s\n", led->regulator_id);
}
}
err = sunxi_get_u32_of_property("reset_ns", &val);
if (!err)
led->reset_ns = val;
err = sunxi_get_u32_of_property("t1h_ns", &val);
if (!err)
led->t1h_ns = val;
err = sunxi_get_u32_of_property("t1l_ns", &val);
if (!err)
led->t1l_ns = val;
err = sunxi_get_u32_of_property("t0h_ns", &val);
if (!err)
led->t0h_ns = val;
err = sunxi_get_u32_of_property("t0l_ns", &val);
if (!err)
led->t0l_ns = val;
err = sunxi_get_u32_of_property("wait_time0_ns", &val);
if (!err)
led->wait_time0_ns = val;
err = sunxi_get_u32_of_property("wait_time1_ns", &val);
if (!err)
led->wait_time1_ns = val;
err = sunxi_get_u32_of_property("wait_data_time_ns", &val);
if (!err)
led->wait_data_time_ns = val;
}
static void sunxi_led_set_all(struct sunxi_led *led, u8 channel,
enum led_brightness value)
{
u32 i;
struct led_classdev *led_cdev;
if (channel%3 == 0) {
for (i = 0; i < led->led_count; i++) {
led_cdev = &led->pcdev_group[i].r.cdev;
mutex_lock(&led_cdev->led_access);
sunxi_set_led_brightness(led_cdev, value);
mutex_unlock(&led_cdev->led_access);
}
} else if (channel%3 == 1) {
for (i = 0; i < led->led_count; i++) {
led_cdev = &led->pcdev_group[i].g.cdev;
mutex_lock(&led_cdev->led_access);
sunxi_set_led_brightness(led_cdev, value);
mutex_unlock(&led_cdev->led_access);
}
} else {
for (i = 0; i < led->led_count; i++) {
led_cdev = &led->pcdev_group[i].b.cdev;
mutex_lock(&led_cdev->led_access);
sunxi_set_led_brightness(led_cdev, value);
mutex_unlock(&led_cdev->led_access);
}
}
}
static ssize_t led_show(struct class *class,
struct class_attribute *attr,
char *buf)
{
struct sunxi_led *led = sunxi_led_global;
sunxi_led_set_all(led, 0, 0);
sunxi_led_set_all(led, 1, 0);
sunxi_led_set_all(led, 2, 0);
sunxi_led_set_all(led, 0, 20);
msleep(500);
sunxi_led_set_all(led, 1, 20);
msleep(500);
sunxi_led_set_all(led, 2, 20);
msleep(500);
sunxi_led_set_all(led, 0, 0);
sunxi_led_set_all(led, 1, 0);
sunxi_led_set_all(led, 2, 0);
return 0;
}
static struct class_attribute led_class_attrs[] = {
__ATTR(light, 0644, led_show, NULL),
//__ATTR_NULL,
};
static void led_node_init(void)
{
int i;
int err;
/* sys/class/led/xxx */
for (i = 0; i < ARRAY_SIZE(led_class_attrs); i++) {
err = class_create_file(led_class, &led_class_attrs[i]);
if (err) {
LED_ERR("class_create_file() failed!\n");
while (i--)
class_remove_file(led_class, &led_class_attrs[i]);
class_destroy(led_class);
led_class = NULL;
}
}
}
static int sunxi_led_probe(struct platform_device *pdev)
{
int err;
struct sunxi_led *led;
struct device *dev = &pdev->dev;
struct resource *mem_res = NULL;
int ret;
dprintk(DEBUG_INIT, "start\n");
led = devm_kzalloc(dev, sizeof(struct sunxi_led), GFP_KERNEL);
if (!led)
return -ENOMEM;
sunxi_led_global = led;
platform_set_drvdata(pdev, led);
led->dev = dev;
mem_res = platform_get_resource(pdev, IORESOURCE_MEM, 0);
if (mem_res == NULL) {
LED_ERR("failed to get MEM res\n");
ret = -ENXIO;
goto emem;
}
if (!request_mem_region(mem_res->start, resource_size(mem_res),
mem_res->name)) {
LED_ERR("failed to request mem region\n");
ret = -EINVAL;
goto emem;
}
led->iomem_reg_base = ioremap(mem_res->start, resource_size(mem_res));
if (!led->iomem_reg_base) {
ret = -EIO;
goto eiomap;
}
led->res = mem_res;
led->output_mode.str = devm_kzalloc(dev, 3, GFP_KERNEL);
if (!led->output_mode.str) {
ret = -ENOMEM;
goto ezalloc_str;
}
sunxi_get_para_of_property(led);
err = led_regulator_request(led);
if (err < 0) {
LED_ERR("request regulator failed!\n");
ret = err;
goto eregulator;
}
err = sunxi_register_led_classdev(led);
if (err) {
LED_ERR("failed to register led classdev\n");
ret = err;
goto eclassdev;
}
sunxi_ledc_set_time(led);
led->reset = devm_reset_control_get(&pdev->dev, NULL);
if (IS_ERR(led->reset)) {
LED_ERR("get reset clk error\n");
return -EINVAL;
}
ret = reset_control_deassert(led->reset);
if (ret) {
LED_ERR("deassert clk error, ret:%d\n", ret);
return ret;
}
sunxi_clk_init(led);
init_waitqueue_head(&led->wait);
err = sunxi_ledc_irq_init(led);
if (err) {
LED_ERR("failed to init irq\n");
ret = err;
goto eirq;
}
sunxi_ledc_pinctrl_init(led);
#ifdef CONFIG_DEBUG_FS
sunxi_led_create_debugfs(led);
#endif /* CONFIG_DEBUG_FS */
led_class = class_create(THIS_MODULE, "led");
if (IS_ERR(led_class)) {
LED_ERR("class_register err\n");
class_destroy(led_class);
ret = -EFAULT;
goto eclass;
}
led_node_init();
dprintk(DEBUG_INIT, "finish\n");
return 0;
eclass:
#ifdef CONFIG_DEBUG_FS
sunxi_led_remove_debugfs(led);
#endif /* CONFIG_DEBUG_FS */
sunxi_ledc_irq_deinit(led);
eirq:
sunxi_unregister_led_classdev(led);
sunxi_clk_deinit(led);
eclassdev:
led_regulator_release(led);
eregulator:
kfree(led->output_mode.str);
ezalloc_str:
iounmap(led->iomem_reg_base);
led->iomem_reg_base = NULL;
eiomap:
release_mem_region(mem_res->start, resource_size(mem_res));
emem:
kfree(led);
return ret;
}
static int sunxi_led_remove(struct platform_device *pdev)
{
struct sunxi_led *led = platform_get_drvdata(pdev);
class_destroy(led_class);
#ifdef CONFIG_DEBUG_FS
sunxi_led_remove_debugfs(led);
#endif /* CONFIG_DEBUG_FS */
if (led->dma_chan) {
dmaengine_terminate_all(led->dma_chan);
dma_release_channel(led->dma_chan);
led->dma_chan = NULL;
}
sunxi_ledc_irq_deinit(led);
sunxi_unregister_led_classdev(led);
sunxi_clk_deinit(led);
led_regulator_release(led);
kfree(led->output_mode.str);
led->output_mode.str = NULL;
iounmap(led->iomem_reg_base);
led->iomem_reg_base = NULL;
release_mem_region(led->res->start, resource_size(led->res));
kfree(led);
led = NULL;
dprintk(DEBUG_INIT, "finish\n");
return 0;
}
#if IS_ENABLED(CONFIG_PM)
static inline void sunxi_led_save_regs(struct sunxi_led *led)
{
int i;
for (i = 0; i < ARRAY_SIZE(sunxi_led_regs_offset); i++)
led->regs_backup[i] = readl(led->iomem_reg_base + sunxi_led_regs_offset[i]);
}
static inline void sunxi_led_restore_regs(struct sunxi_led *led)
{
int i;
for (i = 0; i < ARRAY_SIZE(sunxi_led_regs_offset); i++)
writel(led->regs_backup[i], led->iomem_reg_base + sunxi_led_regs_offset[i]);
}
static void sunxi_led_enable_irq(struct sunxi_led *led)
{
enable_irq(led->irqnum);
}
static void sunxi_led_disable_irq(struct sunxi_led *led)
{
disable_irq_nosync(led->irqnum);
}
static int sunxi_led_gpio_state_select(struct sunxi_led *led, char *name)
{
int err;
struct pinctrl_state *pctrl_state;
pctrl_state = pinctrl_lookup_state(led->pctrl, name);
if (IS_ERR(pctrl_state)) {
dev_err(led->dev, "pinctrl_lookup_state(%s) failed! return %p\n",
name, pctrl_state);
return PTR_ERR(pctrl_state);
}
err = pinctrl_select_state(led->pctrl, pctrl_state);
if (err < 0) {
dev_err(led->dev, "pinctrl_select_state(%s) failed! return %d\n",
name, err);
return err;
}
return 0;
}
static void sunxi_led_enable_clk(struct sunxi_led *led)
{
clk_prepare_enable(led->clk_ledc);
clk_prepare_enable(led->clk_cpuapb);
}
static void sunxi_led_disable_clk(struct sunxi_led *led)
{
clk_disable_unprepare(led->clk_cpuapb);
clk_disable_unprepare(led->clk_ledc);
}
static int sunxi_led_power_on(struct sunxi_led *led)
{
int err;
if (led->regulator == NULL)
return 0;
err = regulator_enable(led->regulator);
if (err) {
dev_err(led->dev, "enable regulator %s failed!\n", led->regulator_id);
return err;
}
return 0;
}
static int sunxi_led_power_off(struct sunxi_led *led)
{
int err;
if (led->regulator == NULL)
return 0;
err = regulator_disable(led->regulator);
if (err) {
dev_err(led->dev, "disable regulator %s failed!\n", led->regulator_id);
return err;
}
return 0;
}
static int sunxi_led_suspend(struct device *dev)
{
struct platform_device *pdev = to_platform_device(dev);
struct sunxi_led *led = platform_get_drvdata(pdev);
dev_dbg(led->dev, "[%s] enter standby\n", __func__);
sunxi_led_disable_irq(led);
sunxi_led_save_regs(led);
sunxi_led_gpio_state_select(led, PINCTRL_STATE_SLEEP);
sunxi_led_disable_clk(led);
reset_control_assert(led->reset);
sunxi_led_power_off(led);
return 0;
}
static int sunxi_led_resume(struct device *dev)
{
struct platform_device *pdev = to_platform_device(dev);
struct sunxi_led *led = platform_get_drvdata(pdev);
dev_dbg(led->dev, "[%s] return from standby\n", __func__);
sunxi_led_power_on(led);
reset_control_deassert(led->reset);
sunxi_led_enable_clk(led);
sunxi_led_gpio_state_select(led, PINCTRL_STATE_DEFAULT);
sunxi_led_restore_regs(led);
sunxi_led_enable_irq(led);
return 0;
}
static const struct dev_pm_ops sunxi_led_pm_ops = {
.suspend = sunxi_led_suspend,
.resume = sunxi_led_resume,
};
#define SUNXI_LED_PM_OPS (&sunxi_led_pm_ops)
#endif
static const struct of_device_id sunxi_led_dt_ids[] = {
{.compatible = "allwinner,sunxi-leds"},
{},
};
static struct platform_driver sunxi_led_driver = {
.probe = sunxi_led_probe,
.remove = sunxi_led_remove,
.driver = {
.name = "sunxi-leds",
.owner = THIS_MODULE,
#if IS_ENABLED(CONFIG_PM)
.pm = SUNXI_LED_PM_OPS,
#endif
.of_match_table = sunxi_led_dt_ids,
},
};
module_platform_driver(sunxi_led_driver);
module_param_named(debug, debug_mask, int, 0664);
MODULE_ALIAS("sunxi leds dirver");
MODULE_ALIAS("platform : leds dirver");
MODULE_LICENSE("GPL v2");
MODULE_VERSION("1.2.3");
MODULE_AUTHOR("Albert Yu <yuxyun@allwinnertech.com>");
MODULE_AUTHOR("liuyu <SWCliuyus@allwinnertech.com>");
MODULE_DESCRIPTION("Allwinner ledc-controller driver");
lichee/linux-5.4/drivers/leds/leds-sunxi.h
/*
* Copyright (C) 2018 Allwinner Technology Limited. All rights reserved.
* Albert Yu <yuxyun@allwinnertech.com>
*
* This program is free software; you can redistribute it and/or modify
* it under the terms of the GNU General Public License version 2 as
* published by the Free Software Foundation.
*
*/
#ifndef __LINUX_LEDS_SUNXI_H
#define __LINUX_LEDS_SUNXI_H
#include <linux/device.h>
#include <linux/list.h>
#include <linux/mutex.h>
#include <linux/rwsem.h>
#include <linux/spinlock.h>
#include <linux/timer.h>
#include <linux/workqueue.h>
#define HEXADECIMAL (0x10)
#define REG_INTERVAL (0x04)
#define REG_CL (0x0c)
#define RESULT_COMPLETE 1
#define RESULT_ERR 2
#define SUNXI_LEDC_REG_BASE_ADDR 0x06700000
#define SUNXI_MAX_LED_COUNT 1024
#define SUNXI_DEFAULT_LED_COUNT 8
#define SUNXI_RESET_TIME_MIN_NS 84
#define SUNXI_RESET_TIME_MAX_NS 327000
#define SUNXI_T1H_MIN_NS 84
#define SUNXI_T1H_MAX_NS 2560
#define SUNXI_T1L_MIN_NS 84
#define SUNXI_T1L_MAX_NS 1280
#define SUNXI_T0H_MIN_NS 84
#define SUNXI_T0H_MAX_NS 1280
#define SUNXI_T0L_MIN_NS 84
#define SUNXI_T0L_MAX_NS 2560
#define SUNXI_WAIT_TIME0_MIN_NS 84
#define SUNXI_WAIT_TIME0_MAX_NS 10000
#define SUNXI_WAIT_TIME1_MIN_NS 84
#define SUNXI_WAIT_TIME1_MAX_NS 85000000000
#define SUNXI_WAIT_DATA_TIME_MIN_NS 84
#define SUNXI_WAIT_DATA_TIME_MAX_NS_IC 655000
#define SUNXI_WAIT_DATA_TIME_MAX_NS_FPGA 20000000
#define SUNXI_LEDC_FIFO_DEPTH 32 /* 32 * 4 bytes */
#define SUNXI_LEDC_FIFO_TRIG_LEVEL 15
#if defined(CONFIG_FPGA_V4_PLATFORM) || defined(CONFIG_FPGA_V7_PLATFORM)
#define SUNXI_FPGA_LEDC
#endif
enum sunxi_ledc_output_mode_val {
SUNXI_OUTPUT_GRB = 0 << 6,
SUNXI_OUTPUT_GBR = 1 << 6,
SUNXI_OUTPUT_RGB = 2 << 6,
SUNXI_OUTPUT_RBG = 3 << 6,
SUNXI_OUTPUT_BGR = 4 << 6,
SUNXI_OUTPUT_BRG = 5 << 6
};
struct sunxi_ledc_output_mode {
char *str;
enum sunxi_ledc_output_mode_val val;
};
enum sunxi_ledc_trans_mode_val {
LEDC_TRANS_CPU_MODE,
LEDC_TRANS_DMA_MODE
};
enum sunxi_ledc_reg {
LEDC_CTRL_REG_OFFSET = 0x00,
LED_T01_TIMING_CTRL_REG_OFFSET = 0x04,
LEDC_DATA_FINISH_CNT_REG_OFFSET = 0x08,
LED_RESET_TIMING_CTRL_REG_OFFSET = 0x0c,
LEDC_WAIT_TIME0_CTRL_REG = 0x10,
LEDC_DATA_REG_OFFSET = 0x14,
LEDC_DMA_CTRL_REG = 0x18,
LEDC_INT_CTRL_REG_OFFSET = 0x1c,
LEDC_INT_STS_REG_OFFSET = 0x20,
LEDC_WAIT_TIME1_CTRL_REG = 0x28,
LEDC_VER_NUM_REG = 0x2c,
LEDC_FIFO_DATA = 0x30,
LEDC_TOTAL_REG_SIZE = LEDC_FIFO_DATA + SUNXI_LEDC_FIFO_DEPTH
};
enum sunxi_ledc_irq_ctrl_reg {
LEDC_TRANS_FINISH_INT_EN = (1 << 0),
LEDC_FIFO_CPUREQ_INT_EN = (1 << 1),
LEDC_WAITDATA_TIMEOUT_INT_EN = (1 << 3),
LEDC_FIFO_OVERFLOW_INT_EN = (1 << 4),
LEDC_GLOBAL_INT_EN = (1 << 5),
};
enum sunxi_ledc_irq_status_reg {
LEDC_TRANS_FINISH_INT = (1 << 0),
LEDC_FIFO_CPUREQ_INT = (1 << 1),
LEDC_WAITDATA_TIMEOUT_INT = (1 << 3),
LEDC_FIFO_OVERFLOW_INT = (1 << 4),
LEDC_FIFO_FULL = (1 << 16),
LEDC_FIFO_EMPTY = (1 << 17),
};
enum sunxi_led_type {
LED_TYPE_R,
LED_TYPE_G,
LED_TYPE_B
};
struct sunxi_led_info {
enum sunxi_led_type type;
struct led_classdev cdev;
};
struct sunxi_led_classdev_group {
u32 led_num;
struct sunxi_led_info r;
struct sunxi_led_info g;
struct sunxi_led_info b;
};
static u32 sunxi_led_regs_offset[] = {
LEDC_CTRL_REG_OFFSET,
LED_RESET_TIMING_CTRL_REG_OFFSET,
LED_T01_TIMING_CTRL_REG_OFFSET,
LEDC_WAIT_TIME0_CTRL_REG,
LEDC_WAIT_TIME1_CTRL_REG,
LEDC_INT_CTRL_REG_OFFSET,
#ifndef SUNXI_FPGA_LEDC
LEDC_DATA_FINISH_CNT_REG_OFFSET,
#endif
};
struct sunxi_led {
u32 reset_ns;
u32 t1h_ns;
u32 t1l_ns;
u32 t0h_ns;
u32 t0l_ns;
u32 wait_time0_ns;
unsigned long long wait_time1_ns;
u32 wait_data_time_ns;
u32 irqnum;
u32 led_count;
u32 *data;
u32 length;
u8 result;
spinlock_t lock;
struct device *dev;
dma_addr_t src_dma;
struct dma_chan *dma_chan;
wait_queue_head_t wait;
struct timespec64 start_time;
struct clk *clk_ledc;
struct clk *clk_cpuapb;
struct pinctrl *pctrl;
void __iomem *iomem_reg_base;
struct resource *res;
struct sunxi_ledc_output_mode output_mode;
struct sunxi_led_classdev_group *pcdev_group;
struct dentry *debugfs_dir;
char regulator_id[16];
struct regulator *regulator;
struct reset_control *reset;
u32 regs_backup[ARRAY_SIZE(sunxi_led_regs_offset)];
};
enum {
DEBUG_INIT = 1U << 0,
DEBUG_SUSPEND = 1U << 1,
DEBUG_INFO = 1U << 2,
DEBUG_INFO1 = 1U << 3,
DEBUG_INFO2 = 1U << 4,
};
#endif /* __LINUX_LEDS_SUNXI_H */
kernel/linux-5.4/arch/riscv/boot/dts/sunxi/sun20iw1p1.dtsi
ledc: ledc@2008000 {
#address-cells = <1>;
#size-cells = <0>;
compatible = "allwinner,sunxi-leds";
reg = <0x0 0x02008000 0x0 0x400>;
interrupts-extended = <&plic0 36 IRQ_TYPE_LEVEL_HIGH>;
interrupt-names = "ledcirq";
clocks = <&ccu CLK_LEDC>, <&ccu CLK_BUS_LEDC>;
clock-names = "clk_ledc", "clk_cpuapb";
dmas = <&dma 42>, <&dma 42>;
dma-names = "rx", "tx";
resets = <&ccu RST_BUS_LEDC>;
reset-names = "ledc_reset";
status = "disable";
};
@chen0505 PA引导是BROM不支持，BROM是固化在芯片里的，如果需要修改需要改版芯片
| Note | Description |
|---|---|
| D/S | Datasheet Support but no sample test |
| S/T | Support and sample test |
| √ | Support and mass produce |
| X | Not support |
| (Blank) | Can support but not support now |
| Part Number | Capacity | JEDEC ID | PACKAGE | R128 Support Status |
|---|---|---|---|---|
| MT29F2G01ABAGDSF-AAT(NW794) | 256M | 0x2C, 0x24 | SOP-16 | D/S |
| MT29F1G01ABAFDSF-AAT(NW808) | 128M | 0x2C, 0x14 | SOP-16 | D/S |
| MT29F2G01ABAGDWB | 256M | 0x2C,0x24 | SOP-16 | D/S |
| W25N01GVZEIG | 128M | 0xEF 0xAA 0x21 | D/S | |
| W25N02KVZEIR | 256M | 0xEF 0xAA 0x22 | ||
| MX35LF2GE4AB | 256M | 0xC2 0x22 | 16-SOP | |
| MX35LF1GE4AB | 128M | 0xC2 0x12 | 8-WSON | √ |
| MX35LF2GE4AD | 256M | 0xC2 0x26 0x03 | 8-WSON | D/S |
| MX35LF1G24AD | 128M | 0xC2 0x14 | ||
| MX35LF4GE4AD | 512M | |||
| GD5F1GQ4UBYIGR | 128M | 0xC8 0xD1 | 8-pad 8X6 WSON | D/S |
| GD5F2GQ4UB9IGR | 256M | 0xC8 0xD2 | 8-pad 8X6 WSON | D/S |
| GD5F1GQ4UCYIG | 128M | 0xC8 0xB1 0x48 | WSON8(8x6mm) | D/S |
| GD5F1GQ5UEYIG | 128M | 0xC8 0x51 | D/S | |
| GD5F2GQ5UEYIGR | 256M | 0xC8 0x52 | ||
| GD5F4GQ6UEYIG | 512M | 0xC8 0x55 | ||
| F50L1G41LB(2M) -> F50L1G41LB-104YG2M F50L1G41LB-104YG2ME | 128M | 0xC8 0x01 0x7F 0x7F 0x7F | 8-WSON | D/S |
| F50L2G41XA | 256M | 0x2C, 0x24 | ||
| DS35Q1GA-1B | 128M | 0xE5 0x71 | 8-WSON | D/S |
| DS35Q2GA-IB | 256M | 0xE5 0x72 | ||
| DS35Q2GBXXX | 256M | 0xE5 0xf2 | ||
| DS35Q4GMXXX | 512M | 0xE5 0xf4 | ||
| DS35X1GBXXX | 1G | 0xE5 0xF1 | 8-WSON | |
| TC58CVG2S0H | 512M | 0x98 0xCD | ||
| TC58CVG0S3HRAIG | 128M | 0x98 0xC2 | 8-WSON | D/S |
| FS35ND01G-S1F1QWFI | 128M | 0xCD 0xB1 | WSON8(8x6mm) | D/S |
| FS35ND01G-S1Y2 | 128M | 0xCD 0xEA | WSON8 | |
| F35SQA001G | 128M | 0xCD 0x71 | WSON8 | √ |
| F35SQA002G | 256M | 0xCD 0x72 | ||
| EM73C044VCD-H | 128M | 0xD5 0x1C | 8-WSON | |
| EM73E044SNA | 128M | 0xD5 0x03 | 8-WSON | |
| ZD35Q1GA-IBR | 128M | 0xba 0x71 | 8-WSON | D/S |
| PN26G01AWSIUG | 128M | 0xa1, 0xe1 | WSON8(8x6mm) | |
| XT26G01A | 128M | 0x0b,0xe1 | D/S | |
| XT26G02A | 256M | 0x0b,0xe2 | ||
| XT26G04A | 512M | 0x0b,0xe3 | WSON8(8x6mm) | |
| XT26G01CWSIG | 128M | 0x0b,0x11 | D/S | |
| XT26G02CWSIG | 256M | 0x0b,0x12 | ||
| XT26G04CWSIG | 512M | 0x0b,0x13 | ||
| XT26G02ELGIGA | 256M | 0x2c, 0x24 | ||
| FM25S01 | 128M | 0xa1,0xa1 | WSON8(8x6mm) | |
| FM25S01A | 128M | 0xa1,0xe4 | ||
| FM25S02A | 256M | 0xa1,0xe5 | ||
| SCN00SA3W1AI8A | 128M | 0xC8 0x21 | 8-WSON | |
| S35ML01G3 | 128M | 0x01 0x15 | ||
| S35ML02G300WH100 | 256M | 0x01 0x25 | ||
| S35ML04G3 | 512M | 0x01 0x35 | ||
| HYF1GQ4UDACAE | 128M | 0xC9 0x21 |
支持NAND的，下图的5个模块分别是NOR和NAND，
启动使用的SPI是在PB组，需要挂在PB上才能启动，并且需要专门配置的SDK，可以在SDK中看到有NAND的选项
附上两种存储介质的启动流程：
NOR：
NAND：
同时也支持 eMMC、SD-NAND启动
从 log中可以看到，
[ 0.293211] disp 0, clk: pll(426000000),clk(426000000),dclk(71000000) dsi_rate(71000000)
[ 0.293211] clk real:pll(420000000),clk(420000000),dclk(105000000) dsi_rate(150000000)
内核引脚正确初始化并执行送图，Uboot运行而Kernel不执行函数是因为Kernel驱动当接收到Uboot传入的显示屏信息后不会重新初始化屏幕，这样可以保证整个开机logo显示流畅。
这里log看到的驱动是ICN6202 TO LVDS，这是一颗转换MIPI DSI 转 LVDS的芯片，其MIPI初始化数据与普通 MIPI 屏幕不同，请检查下是否使用了正确的初始化。
MIPI 与 RGB 不同，MIPI需要配置屏幕的参数，需要针对屏幕编写驱动
@king-zhao aw859a 的 WIFI 驱动可以在 OrangePi 官方仓库里找到
@hgs1975 This is not a error, you can normal boot up while showing this error. What's your hardware and how to configure it
